Marcel Erz has put up a GitHub with assorted Model I parts which can be 3-D Printed!

Currently present are:

• Main Enclosure Panel
• PCB Stand-Off
• Keyboard Stem (ALPS)
• Keyboard Spacebar Clip
• Keyboard Clip
• Keyboard Button Placeholder (Enter)
• Keyboard Shield
• Extension Interface Cover (Medium)

You check it all out at [Hotlinks Removed From Old News Pages] https://github.com/RetroStack/TRS-80-Model-I-3D-Objects.

Lawrence Kesteloot has updated his TRS80TOOL to v2.6.0. Release Notes:

• Better handling of double-sided disks.
• Assembler:
  • Full expression support: All the operators in C, with their same precedence.
  • Assembles about 10 times faster.
  • Allow nv and v for po and pe flags.
  • Various compatibility improvements with zmac.
  • Breaking change: No longer permit % as binary prefix. Instead of writing %1010, use 1010b or 0b1010.
• Disassembler: Add --upper flag.

You can download it at https://www.my-trs-80.com/tool/

Shawn Sijnstra has updated his Infocom Executors ... Model I and III to version 7 and Model 4 to version 17.

Full list of credits, features and issues as well as the source and compiled code are in the Gitlab page:

• https://gitlab.com/sijnstra1/m1zvm for Model I
• https://gitlab.com/sijnstra1/m3zvm for Model III
• https://gitlab.com/sijnstra1/m4zvm for Model 4

A site visitor has a working Model 4 (or at least drive :0 does) for sale for $300 for local pickup. Unit does have a loose connection in the plug at the power supply that powers the CRT filament, although most of the time the connection is good as is. Probably an easy fix. Drive 1 works when in Drive 0 position, so perhaps there is an issue with the controller or cable for the :1 position.

Seller is located about 100 miles NW of San Antonio, TX a few miles off of I-10; and could meet in or around Kerrville, Texas if that's better.

Marcel Erz has reverse engineered the Model I ALPS keyboard PCB. He says

This project is a faithful reimplementation of the ALPS keyboard PCB of the iconic TRS-80 Model 1 computer. My revision, the E1, is designed to replicate the PCB design 1-to-1 of the original down to the traces. The entire project is available under the MIT license.

Visit the https://github.com/RetroStack/TRS-80-Model-I-Keyboard-ALPS GITHub Page for gerber files, Bill of Materials (CSV and PDF formats), layers exported in PDF and SVG formats, and full schematics of the E1 replica which is 1:1 to the original G board.

Jeff Birt was kind enough to bid, and then scan, the missing Portable Disk Drive 2 Service Manual. Thank you Jeff!

Title: Portable Disk Drive 2 Service Manual
Publisher: Tandy
Year: 1987
Size: 84,173,485
Pages: 108
Notes: [26-3814]

I have stumbled upon another disk format which TRSTools does not properly handle. I have tried to go through my old emails to find all the old reports, but many of them just sent disk images of which I no longer have records.

So ... to those who use TRSTools and TRSREAD, please tread carefully on the following DOS image types:

• MultiDOS double sided disks. TRSTools/TRSREAD will sometimes insert the side 2 data in the middle of side 1 files. I confirmed this by batch reading each disk double sided and then again as single sided, extracting the files, and comparing them. VDISK (by Miguel Dutra) extraction resulted in 100% identical crc's between those sets. TRSREAD had multiple differences, where the Double Sided disk read was corrupt.
• TRSDOS v2.3b disks.
• DosPlus 3.4A for the Model III.
• NEWDOS/80 images with damage on Track 1.
• TRSDOS v2.77D, particularly deleting files, as they may corrupt the image.
• TRSDOS 1.3 disks with extra data in a reserved area of the directory.

Right now, I have a slew of MultiDOS double sided disks (and CP/M double sided disks) where side 2 is inaccessible. The CP/M disks are entirely unusable; and that may be because they were made on a Model III with a Shuffleboard or because no tool exists to identify the geometry needed to mount them. The MultiDOS disks read (on a catweasel) as double-sided disks, but only Side 1 shows up in an emulator, and side 2 cannot be separately read as its own image.

Brick Parrish, who is still looking to sell a Model (See January 9th news item), sent over two manuals for scanning. Thank you, Brick!

Title: DOSPlus v3.4-4.0 vA.2
Publisher: Micro-Systems Software
Year: 1982
Size: 523,279,115
Pages: 248

Title: Fortran
Publisher: Tandy
Year: 1981
Size: 664,512,098
Pages: 273
Notes: [M3][26-2200]

Brick Parrish, who is still looking to sell a Model 4 (See January 9th news item), sent over another manuals for scanning. Thank you, Brick!

Title: Modem I
Publisher: Tandy
Year: 1981
Size: 18,992,572
Pages: 15
Notes: [26-1172][v8749285-SP-281]

Dusty was kind enough to pass on the manual for Decision Master. Thank you Dusty!

Title: Decision Maker
Publisher: Syntonic Software Corporation
Year: 1981
Size: 114,458,177
Pages: 88

Bill Allen has sent over a bunch of manuals for me to scan. The first set is below. Thank you, Bill!

Title: UltraDOS and SuperBASIC Reference Manual
Publisher: Vernon B Hester-Level IV Products
Year: 1980
Size: 205,822,671
Pages: 89
Notes: [2nd Printing]

Title: LDOS v5.1.x 1st Ed
Publisher: Logical Systems Inc
Year: 1982
Size: 751,777,287
Pages: 292
Notes: [Combined Model I and III]

More manuals, courtesy of Bill Allen and Brick Parrish

Title: BASCOM Basic Compiler v5.11
Publisher: Tandy
Year: 19xx
Size: 516,702,297
Pages: 274

Title: NEWDOS v2.1 Changes
Publisher: Apparat
Year: 19xx
Size: 188,988,633
Pages: 48

Title: CPM-TRS-PC File Interchange Program v1.0
Publisher: Hypersoft
Year: 1984
Size: 30,192,468
Pages: 15

More manuals, Brick Parrish

Title: MVB-3 80 x 24 Video Board Installation and User Guide
Publisher: Memory Merchant
Year: 1983
Size: 154,889,241
Pages: 60

Title: ShuffleBoard III Users Manual v1.0 and Addendums
Publisher: Memory Merchant
Year: 1981
Size: 1,218,545,583
Pages: 110

Title: M3CBI Model Model III Communications Board Manual
Publisher: Computex
Year: 1982
Size: 133,853,141
Pages: 50

Title: Trendex Stock Market Trend Analysis
Publisher: Tandy
Year: 19xx
Size: 145,908,901
Pages: 51
Notes: [26-1509]

Title: Trilogy Drive Controller Kit for Model III User Manual
Publisher: World Wide Data Systems Inc
Year: 1983
Size: 254,676,097
Pages: 42

William Bares was kind enough to scan the missing Alien Armada manual. Thank you, William!

Title: Alien Armada
Publisher: Waldron P Hodsdon
Year: 1981
Size: 630,356
Pages: 4

Amardeep was kind enough to provide the articles he had collected regarding installing 4164 RAM chips in a Model I.

• Article by Errol Rosser
• Article by McCoy and Treasure
• Article by Don Kelly

More manuals, Brick Parrish

Title: Talker v2.0 Users Manual
Publisher: Alpha Products
Year: 1979
Size: 44,107,158
Pages: 17
Notes: [Set 1]

Title: VS-100 Voice Synthesizer User Manual
Publisher: Alpha Products
Year: 1983
Size: 80,191,508
Pages: 40

William Bares was kind enough to lend me some tapes to read!

Title: Alien Armada
NOTE: None of the existing WAV to CAS programs properly converted this to CAS. To run this, you will need to use TRS32 or other emulator which can process WAV files.

Title: Iago

Title: Scarfman

Eddie, of https://tandyshowcase.com/ has scanned some Sacramento Tandy Users Group newsletters!

Title: SACTUG
Issue: Vol 1 No 1
Publisher: Sacramento Tandy Users Group
Year: 1986
Size: 41,896,038
Pages: 8

Title: SACTUG
Issue: Vol 2 No 1
Publisher: Sacramento Tandy Users Group
Year: 1987
Size: 73,312,238
Pages: 10

Title: SACTUG
Issue: Vol 2 No 3
Publisher: Sacramento Tandy Users Group
Year: 1987
Size: 59,664,335
Pages: 10

William Bares had also lent some disks ...

Title: Super Script (Model 3)

Title: Alien Armada

Title: MyChess

Jay Crutti has designed a full Model 4 keyboard replacement.

Right now, you can build it yourself, although Jay is contemplating selling them in the future.

A site visitor has a working Model 4 (or at least drive :0 does) for sale for $300 for local pickup. Unit does have a loose connection in the plug at the power supply that powers the CRT filament, although most of the time the connection is good as is. Probably an easy fix. Drive 1 works when in Drive 0 position, so perhaps there is an issue with the controller or cable for the :1 position.

Seller is located about 100 miles NW of San Antonio, TX a few miles off of I-10; and could meet in or around Kerrville, Texas if that's better.

Ian Mavric was kind enough to provide the Model 4 Service Manual Addendum. Thank you, Ian!

Title: Model 4 and Model 4 Gate Array Service Manual Addendum
Publisher: Tandy
Year: 1985
Size: 6,420,877

TRS8BIT - Vol 18, No. 1

We have the first news of the 2024 competition from George Phillips. There are articles from Ian Mavric on replacing Co-Co 2 keyboard membranes, a very detailed account of the FB series of disk drives and looks forward to the 2024 T.A. Jim Adams hunts down the start of BASIC making, what is a 'must go to' guide. E.T. Fonehume creates a BASIC one-liner to print a 5x5 magic square using consecutive numbers. Juergen Buessert explains how to create a 'WAV' file from a DMK image. Vince Otten continues his series 'Software Tools in BASIC' with episode 3, 'Open For Business' and an article using ROM calls from TRSDOS. Tony G sends details of various pieces of hardware he created, 'back in the day'. And, of course, there's the regular features of 'The Way We Were', U.K. Ebay bargains, various finds from 'Surfin the Net' and finally, there's a BASIC one-liner game for all you M2 fans. (Is this a first I wonder?)

Issue Information:

Table of Contents:

Quentin Barnes has updated the Catweasel Utilities to v4.10

New to this release are:

• Add -S option. This option allows the user to specify a minimum number of sectors per track and side. If that minimum is not reached during a read, it'll trigger a retry.
• Extend the -x and -X option argument syntax when specifying a track range to also allow giving sides.
• Add partial support for RX02 in dmk2jv3.

The -S is a feature that I find to be a necessary evil. Many disks with issues can erroneously report an end of track data before all the retries are finished, and CW2DMK would then decide "Oh, OK - then this track is 7 good sectors" when it really is "7 good, 11 bad" that was just mishandled. With this, you can make a second pass that FORCES CW2DMK to keep re-reading until it either gets 18 good sectors or the retry count expires.

The main GITHUB can found at https://github.com/qbarnes/cw2dmk/

After a LOT of work (including an entire new pass over the entire Level II ROM disassembly), I have completed a commented disassembly of BASIC/CMD as was packaged with TRSDOS v2.3

The disassembly of BASIC/CMD can be found on this site.

Steve H. has sent in a bunch of scans ... Thank you, Steve!

Catalogs

Title: CLOAD Magazine
Publisher: CLOAD Magazine
Year: 19xx
Size: 709,924
Pages: 2

Title: Computer TEXTile Catalog
Publisher: Computer TEXTile
Year: 19xx
Size: 2,888,502
Pages: 6

Title: TRS Yellow Page
Publisher: Micro Architect
Year: 1978
Size: 2,581,055
Pages: 8
Notes: [78-11]

Magazines

Title: CLOAD Magazine 1978-08
Publisher: CLOAD Magazine Inc
Year: 1978
Size: 1,493,333
Pages: 4
Notes: [Set 2]

Title: Level One Magazine
Publisher: Level One Magazine
Year: 19xx
Size: 1,359,518
Pages: 4

Title: TRS-80 Computing
Issue: Vol 1 No 1
Publisher: Computer Information Exchange Inc
Year: 1978
Size: 16,654,542
Pages: 32

Service Manuals

Title: 16K RAM Expansion Service Manual Addendum
Publisher: Tandy
Year: 1978
Size: 758,978
Pages: 4
Notes: [26-1101]

Hardware Manuals

Title: Important Notice Regarding Model I Mini-Disk Drives
Publisher: Radio Shack
Year: 19xx
Size: 240,607
Pages: 1

Title: Model I Double Density System Start-Up
Publisher: Tandy
Year: 19xx
Size: 2,445,499
Pages: 2

Title: Oasis Systems Light Pen Users Manual
Publisher: Oasis Systems
Year: 1980
Size: 2,269,574
Pages: 11

Thanks to eagle eyed David S, I am told that Jens Guenther has updated his Windows/Linux fork of the SDLTRS Emulator to v1.2.29

Changelog:

• Added 1024 KB memory support for TCS Genie IIIs.
• Added 512 KB memory support for TRS-80 Model I Selector.
• Added 2nd printer MMIO for TRS-80 Model III/4/4P.
• Added more shortcuts for command line options.
• Added SDL2 aspect ratio option in GUI.
• Added debugger command to change Z80 HALT action.
• Fixed TRS-80 Model 4 MMIO in map 0.
• Fixed redraw of HRG1B screen.
• Fixed IMPORT.COM utility for CP/M 3.0.
• Fixed debugger alternate register set assignment by Nick Andrew.

You check it all out at https://gitlab.com/jengun/sdltrs/-/releases

Lawrence Kesteloot has updated his TRS80TOOL to v2.7.0. Release Notes:

• In the run command, if the mounted floppy is modified, the changes will be written to the underlying virtual floppy file. Specify the --write-protected option to mount the floppy write-protected.
• The dir command has a new --system option to show system files.

You can download it from https://www.my-trs-80.com/tool/

George and Peter Phillips have updated their awesome TRS80GP emulator to v2.5.3. Changes are:

New Features:

• Model I/III/4 now accept .wav files as cassette input.
• Add -pp/-ppx options to control printer window pop-up.
• Model I RS-232 sense switches (thanks to Tuc for hardware tests).
• Add loopback device to RS-232 choices (-r :loop on command line)
• Add -rx option to disable RS-232 on Model I,2,III,4,12,16.
• Semigraphics 6 modes will display alternate palette (Electric Crayon, MC-10, CoCo).
• Add "-im disksummary" and disksummary on drive exports to output a summary of drive structure just like the Disk Viewer window.

Bug Fixes:

• $37EA and $37EB are now memory mapped printer port alises on Model I.
• Model I/III/4 RS-232 receive bug fixed.
• CoCo BASIC ROM 1.0 printer output fixed.
• Text pasting works for CoCo 1.0 and 1.1 ROMs.
• Printer auto-turbo works for all models now.
• Model 4 software keyboard no longer missing '+' character on keycap.
• trs80gp -m1 -dx no longer loads lower case driver by default; use -lld to do so.

You can download it at http://48k.ca/trs80gp.html

The next TRS-80 Trash Talk live show is Saturday, May 4, 2024 at 2:00PM Pacific Daylight Time / 5:00PM Eastern Daylight Time!

You can watch on the TRS-80 Trash Talk channel: https://www.youtube.com/channel/UCXkGugvdCkpkMDylVQb9gfg

If you want to participate in the live zoom session, reach out to trs80trashtalk at gmail dot com for information.

Marcel Erz has just release a schematic to enable the connection of an original TRS-80 keyboard to a modern computer via USB which supports multiple TRS-80 models and various development boards for interfacing the keyboard with a system over USB.

You can find the GIT at https://github.com/RetroStack/TRS-80-USB-Keyboard

Quentin Barnes has updated the Catweasel Utilities to v4.10.1

New to this release are:

• Fix indefinite looping while guessing head stepping rate when encountering unusually formatted disks, often from copy protection.
• Fix bug with wraparound detection when the duplicate ID block gets cut off by the DMK buffer filling up. The fix is to stop decoding when the buffer fills up, so that we don't detect such a header in the first place.

The main GITHUB can found at https://github.com/qbarnes/cw2dmk/

Ian has kindly provided a scan of the LS-LED manual!

Title: LS-LED
Year: 1983
Company/Author: Logical Systems Inc
Size: 6,678,177
Pages: 15

L Curtis Boyle let me know that Canadian Retro Things posted a two part interview with Robert Kilgus. They write:

While at the 32nd Annual 'Last' Chicago CoCoFest I took a little side trip with L Curtis Boyle. We visited Robert Kilgus, a name you may recognize from a number of TRS-80 Model 1 and CoCo programs. We sat down with Robert, here is part one of the interview covering his early days, before doing anything for Tandy.

You can watch Part 1, entitled "The Early Years" at https://www.youtube.com/watch?v=zQAq5wNLcCo and Part 2, entitled "The TRS 80 Model 1 Years" at https://www.youtube.com/watch?v=gAqG0lSyuLs

While they were it, they secured permission from Robert to post his sofware and books, so you can download his book, Inside Microfiles and all of Robert's files have now been made downloadable via the Software Seach Page.

Ian has kindly provided a scan of the Quizmaster Manual!

Title: QuizMaster
Publisher: Logical Systems
Year: 1982
Size: 7,362,857
Pages: 18

Ian has kindly provided a scan of the LDOS 5.3 Model 4 Interface Kit Manual!

Title: LDOS 5.3 Model 4 Interface Kit
Publisher: Misosys Inc
Year: 1987
Size: 11,218,690
Pages: 14
Notes: [Blue Cover]

L Curtis Boyle let me know that Canadian Retro Things posted two more parts of his interview with Robert Kilgus.

Part 3 covers the main part of his career with the Coco from 1979-1984, including selected as one of the few to get the earliest prototypes of the TRS-80 Color Computer, the cross development system he used for the earliest Coco programs, and developing his Coco specific programs and games. You can watch that at https://youtu.be/kJT9T2apvvs?si=6kYwYM_p10q57jtR

Part 4 (the final part) finishes covering the Coco (including the unreleased OS-9 Scripsit from 1984) and his final home computer (multi-platform) project - and what went wrong there. And a bit of what he is following these days. You can watch that at https://youtu.be/uwuS4dFg93o?si=T3RAXmxPugyQuTsb

Arno, Sascha, and Lawrence Kesteloot will be running the second Bay Area Tandy Meetup on June 15, 2024!

If you are interested in the meet-up, please visit https://docs.google.com/forms/d/e/1FAIpQLSc9ZDlEGBrd6okI9xIoKPjwLb4kHmdVFPvNog4lOUPEe5NaLQ/viewform

Marcel Erz's TRS-80 RetroStack projects continue to be completed.

Read about the recently finished Model 1 case replication project at https://www.patreon.com/posts/trs-80-model-1-104571852

And peruse his other finished projects including a 'Fake Keyboard Bezel' case that works with a Raspberry Pi and modern USB or wireless keyboards, a mini case, and about many others at https://www.patreon.com/posts/summary-update-105541104

Sign up for his Patreon and encourage him to complete the many special projects such as a TRS-80 Model 1 Japanese Replica, an improved version of the Model 1, or for the Norcom TC-III replica - A Model 3 in the form factor of a Model I.

Marcel Erz's RetroStack is also hosting a noteworthy project by Ven Reddy: the Model 1 Test Harness. This device utilizes the *TEST signal on the edge card connector for system testing without needing to swap ROMs. The project is still in progress, so follow it at https://www.patreon.com/collection/298425

Issue Information:

Table of Contents:

If you need a replacement keyboard for your TRS-80, Jay Crutti has developed a few models

You can visit Jay's web site at https://www.jaycrutti.com/hardware-projects/tandy-trs-80-replacement-keyboards

The next TRS-80 Trash Talk live show is Saturday, July 6, 2024 at 6:00PM Pacific Daylight Time / 9:00PM Eastern Daylight Time!

You can watch on the TRS-80 Trash Talk channel: https://www.youtube.com/channel/UCXkGugvdCkpkMDylVQb9gfg

If you want to participate in the live zoom session, reach out to trs80trashtalk at gmail dot com for information.

George Philips to the rescue AGAIN! The diskette request page has been fixed.

If you had a request in and never heard back, please re-submit!

Pete Cetinski has provided the report which Tandy got back when it tested the Model I for RFI. The Model I was discontinued based on these findings.

Jim McGinley has start up a GAMES I USED TO PLAY webpage.

The site uses TRS80GP to highlight 30 of his favourite TRS-80 games (6 so far are posted). A snapshot feature is present which allows the games to be saved and loaded, so people can start at higher levels.

You can check out the site at http://www.bigpants.ca/gamesiusedtoplay

The Model 4 ROMs have been disassembled. The same single page houses v1, v2, and the Network Student Edition ROM.

Jens Guenther has updated his Windows/Linux fork of the SDLTRS Emulator to v1.2.30

Changelog:

• Added LNW80 Model II banking and 80x24 text mode support.
• Added 1024 KB memory support for Alpha Technology SuperMem.
• Added Alpha Technology SuperMem for TRS-80 Model 4/4P.
• Added Real Time Clock/Calendar Card (RTCC) for TRS-80 Model I.
• Added TRS-80 Model I printer address aliases.
• Added maskable interrupt in IM0 and IM2.
• Added turbo mode deactivation while any keys are pressed.
• Fixed scaling of block graphic characters for Model 4/4P.
• Fixed Z80 HALT action to run debugger.
• Fixed bugs and internal improvements.

You check it all out at https://gitlab.com/jengun/sdltrs

Dennis Brent, Kim Watt's partner at PowerSoft, has passed away.

You can read the obituary at https://www.dignitymemorial.com/obituaries/dallas-tx/dennis-brent-11935900

TRS8BIT - Vol 18, No. 3

In this 100 page edition of all things Tandy, Ian Mavric updates us with the latest news of TA24, he details information on Type2 HDA's for the Model 2 family and reviews the Tandy model 1200. TRS-80 BASIC floating points are described in another detailed article by Jim Adams. Pascal Holdry shows his latest work for the 68000 computer boards. 'At The Ready Prompt' is back with 2 very neat ways of checking for odd or even. George Phillips 'Tunes-up' the Co-Co randomising ability. 'The Way We Were' looks at the Exatron Stringy Floppy for the TRS-80. There's details of some of the recent U.K. Ebay bargains. 'Where Are They Now' highlights a prolific contributor to Tandy section of Softside magazine, James Garon. (Sorry about the photo though!). There's time for a bit of fun, checking a maze. E.T. Fonehume checks-out check digits, using a one-liner of course! There's a quick surf around the net. Mark Casteleijn steps through his adventures with the FreHD and TRSVID. Vince Otten explains how to error trap ROM calls from TRSDOS 2.3 And finally, just a reminder, time is running fast to get you competition entries in.

A new upgrade to George and Peter Phillips's TRS-80 emulator. trs80gp (version 2.5.4) will be available shortly. Full details of all the options are available from their website. This really is THE best TRS-80 emulator on the planet. It even has, just for the U.K., Aculab Floppy Tape emulation. Just as 'in the day' but, of course, without any media problems! You can also use the upgraded version of Level 2 BASIC, "TWOHAF" (Level 2.5), using the AFT as well as ordinary cassette BASIC.

Tandy Assembly is happening September 27th - 29th, 2024 in Springfield, Ohio

The big news this year is that TRS-80 creator team of Don French and Steve Leininger will be joining us for the first time and Steve will be giving a keynote speech with Q&A.
All the usual events will be back, like the Friday Tech Track classes, the Saturday afternoon auction and the Saturday evening trivia contest hosted by none other than Ian Mavric!

You can get more information at https://www.tandyassembly.com/

The next TRS-80 Trash Talk live show is Saturday, November 16, 2024 at 6?PM PST

You can watch on the TRS-80 Trash Talk channel: https://www.youtube.com/channel/UCXkGugvdCkpkMDylVQb9gfg

If you want to participate in the live zoom session, reach out to trs80trashtalk at gmail dot com for information.

If you have a collection of TRS-80 software, please consider visiting the Missing TRS-80 Software Page and seeing if you have anything which is missing.

George and Peter Phillips have updated their awesome TRS80GP emulator to v2.5.4. TRS-80 Model I/III/4-related changes are:

New Features:

• Event stream (-event endpoint) allowing external programs to blink LEDs, etc.
• FreHD emulation supports DSK/DCT LDOS driver to mount read-only disk images.
• Hardware serial port access on linux and mac via -r /dev/tty/USB0 or such.

Bug Fixes:

• Cassette now starts if inserted while CLOAD or SYSTEM in progress.
• Control of delay before cassette auto-save via -csd or Cassette -> Save menu.
• Correct Model 3 and 4 memory mapped printer port to be read-only.
• Less awkward breakpoint GUI with a single window and addr1:addr2 for ranges.
• Minor .wav output correction as .wav files should be an even number of bytes.
• Printer window auto scrolls to bottom again on output.
• Printing on LDOS no longer reboots; emulator ignored printer interrupt disable.
• Replaced patched TRSDOS with proper Japanese TRSDOS.
• Show .wav files in cassette open dialog by default if supported.
• Stop quadradic slowdown as printer output grows.

You can download it at http://48k.ca/trs80gp.html

If you have a collection of actual, hard copy, TRS-80 magazines or newsletters, please consider visiting the Missing TRS-80 Magazines Page and seeing if you have anything which is missing.

Quentin Barnes has updated his Greaseweazle software to Alpha 8. Please do not be concerned with the "Alpha" designation - he is being cautious. This software is FAR superior to the software which comes with the Greaseweazle for reading TRS-80 Model I/III/4 disks.

You can download the software at https://github.com/qbarnes/gw2dmk/releases/tag/v0.0.1.alpha.8

Jens Guenther has updated his Windows/Linux fork of the SDLTRS Emulator to v1.2.31

Changelog:

• Added TRS-80 Model III/4/4P NMI bug fix by Joshua Arnold
• Added Model III/4/4P memory mapped printer port to be read-only
• Added filter for supported file types in GUI file browser
• Added window border in fullscreen mode
• Added more shortcuts for command line options
• Fixed command line options for memory expansion cards
• Fixed TCS EG-64 Memory-Banking Adaptor
• Fixed TCS Genie IIs/SpeedMaster RAM 192 B memory card
• Fixed current date in LS-DOS for TRS-80 Model 4/4P
• Fixed Hard Disk Activity LED for SDL2
• Fixed Mouse cursor for selection in scaled SDL2 window
• Fixed some bugs and other improvements

You check it all out at https://gitlab.com/jengun/sdltrs

Mike Gore has done an analysis of the changes to the Model I Rev D and Rev E boards and has written up a piece on how to modify those boards to the last revision, Rev G.

Marcel Erz has done a complete breakdown of all TRS-80 Model I revisions.

You can read about it at https://www.patreon.com/posts/exploring-of-trs-117044053

Dusty has released the December 2024 edition of TRS8BIT magazine.

In this edition, George Phillips announces the winner of the 2024 Competition. Egoitz Campo reports on the latest TRS-80 tournament. Ian Mavric reports on the 2024 Tandy Assembly, reviews the very rare Tandy 10 and wets our appetite with a preview of his work on the Tandy Model 1 reference numbers. Vince Otten has the penultimate edition of his 'Software Tools in BASIC'. There's a report on some of the Ebay 'bargains' since our last issue and E.T. Fonehume has a one-liner for checking if a number is PRIME. 'The Way We Were' takes us back-to-the-day. 'Just for fun' sets another maze for you to try and finally, there is the sad news of the death of T.E. Kurtz, a really forward thinker, who opened the world of computing to many, in a revolutionary way.

You can download it from http://www.fabsitesuk.com/tandy/trs8bit1804.pdf

A big THANK YOU to all of those who have sent in software from the Missing TRS-80 Software Page and seeing if you have anything which is missing.

As always, if you have any of the items on the list, please contact me.

Lawrence Kesteloot has updated his TRS-80 Tool with a new subcommand to the option to focus on bad sectors of a disk image.

The sectors command displays a table of the sectors in a floppy disk. The columns are the sectors and the rows are the tracks. For each sector a character is displayed with:

• - No sector.
• S Single-density sector.
• D Double-density sector.
• X Deleted sector.
• C CRC error (ID or data).
• ? Missing sector.

Use the --contents flag to also show the contents of the sectors.

The new --bad flag lists all sectors that are missing or that have a CRC error, as well as which file (if any) is on each bad sector. Can be combined with --contents to also show the contents of the bad sectors.

The instructions page can be found at https://www.my-trs-80.com/tool/#sectors, executables can be downloaded at https://www.my-trs-80.com/tool/#installation, and the source can be downloaded by choosing DOWNLOAD ZIP from https://github.com/lkesteloot/trs80.

I misunderstood someone's request and disassembled TRSDOS v2.3's FORMAT/CMD program. Oh well.

You can find that commented disassembly on the TRSDOS v2.3 FORMAT/CMD page.

Jeff Birt has disassembled the 3 versions of the PC-2 ROM. You can download those ROMs and their disassemblies from https://github.com/Jeff-Birt/Sharp_PC-1500_ROM_Disassembly/tree/main

John H has TBBS running on his Model I. To access, telnet (using Putty or similar telnet client; but not a browser) to trs80bbs.tplinkdns.com

For those interested, he is using https://www.cbmstuff.com/index.php?route=product/product&product_id=113 WiModem232 Pro as his modem.

I had received three emails on January 17th that required me to do a little research. In the interim, an accident with FDISK caused me erase my C drive. While I have a daily backup, I lost those 3 emails.

So if you emailed me on the 16th or 17th and didn't get a response, I apologize but I don't have your email address anymore.

If you have an unanswered question from me, please reach back out.

Thanks to Richard Zimmerman and Robert French, Froggy for the ChromaTRS has been added to the archive.

All of Robert French's software is available for download via the TRS-80 Archive Search page, just search for Robert S French in the AUTHOR field.

Disk

Screenshot

Tuc was kind enough to send the Rigid Driver for Model I DOSPlus v3.5 VR Data Hard Drive for archiving.

Ad

Media

Screenshot

Sean O'Neill was kind enough to send MCAP: A Microcomputer Circuit Analysis Program, by Hayden for archiving.

Greaseweazle hardware

Quentin Barnes has released an update to his Greaseweazle software, now at version 0.0.1.beta.1. Supported is Windows 32 and 64 bit varieties, and Linux Aarch64, Arm7L and x86/x64.

IMHO, he is being very conservative with his numbering - the program works perfectly.

You can download it from Quentin's GITHUB at https://github.com/qbarnes/gw2dmk/releases/tag/v0.0.1.beta.1.

If you are dumping your own images, please consider sending them over to me for addition to the archive.

Marcel Erz, through his https://github.com/RetroStack/ Retrostack github page, has put together a lot of modern replacements for TRS-80 Model I/III/4 parts, including motherboards, ROMs, character generators, and various plastic parts.

As of this posting, the site includes:

• Model I:
  • Motherboards: Revision A, D, E, G
  • ROMs: Broken out into 2x64, 2x128, 2x256, and 2x512
  • Keyboards: ALPS and MX
  • Power Supply with 3-D Printable Enclosure
  • Mods: XRX-III
  • Adapters: Keyboard, ROM, and Character Generator
  • 3-D Printable Parts
• Model III and 4:
  • Keyboard Adapter
  • 3-D Printable Parts

Ian Mavric has managed to get his hands on the rare Night Walker by Adventure International. Thank you Ian!

Title: Night Walker
Publisher: Bob Cassady Adventure International
Year: 1983
Size: 8,598,935
Pages: 11

As a reminder ... if you have any disks at all, or any of the software on the known missing page, please consider letting me know.

Jamie Curmi has put up a page discussing the search to locate the program Martian Menace. You can read it at https://curmi.com/martian-menace/.

The Software Archive is unwieldy. Between SUPERZAP and BASIC, so many files were modified by the various users resulting a slightly different versions of otherwise identical files.

In attempting to weed through all these, I realized that I needed to be more descriptive in each filename, so that duplicates could be sussed out.

This entails running every piece of software in the archive, figuring out something that would quickly distinguish one version of, let's say, Star Trek or Othello or Poker, from another, and re-labeling the ZIP with that note. Then, seeing which files have the same label and running them again to see if they are identical and, if so, merging them into a single ZIP file instead of having multiple ZIP files. Then running them all again to get screen shots.

This exercise also allows for discovery of previously missing information, like an embedded author's name in one copy that was removed from another.

So that's what's going on. It is a drastic renaming and recommenting of the archive, but with a reduction in 'Author Unknown' and duplicate entries.

... and it also lets me program, something I don't otherwise do, in developing all the tools and batch files I need to make this jobs somewhat easier. VB6 still works fine under Windows 11, thank goodness!

Scott Atkinson has kindly provided a few Tandy Australia titles. Thank you, Scott!

Title: Bowling
Publisher: Tandy
Year: 19xx
Catalog: 269-7912

Title: Formula One
Publisher: Tandy
Year: 19xx
Catalog: 269-7911

Title: Gun Fighter
Publisher: Tandy
Year: 19xx
Catalog: 269-7953

Title: Helicopter
Publisher: Tandy
Year: 19xx
Catalog: 269-7951

Title: Invaders
Publisher: Tandy
Year: 19xx
Catalog: 269-7913

As a reminder ... if you have any disks at all, or any of the software on the known missing page, please consider letting me know.

Thanks to Darin May, who used to work at Racet Computes, Chris Johnston (the "C" in RACET) has given me permission to make Racet Computes software available for download.

So ... the software archive links and the software manual links are now live.

Thank you Chris and Darin!

UPDATE: Claimed

There is a Model I with expansion interface, 4 drives, and a Line Printer III available for free for local pickup only in Stanton, California. Worked when last turned on; no idea about right now, though.

This is a definite no-ship situation; this stuff would never survive. So please contact me if interested, and I will pass it on!

TRS8BIT - Vol 19, No. 1

Starting our 19th year with a bumper 150+ page edition of TRS8BIT! Thanks to everyone who have contributed articles. There's first sight of the main 2025 competition 'IMPOSSiPUZZLE25'. Great prize on offer, so get your thinking-heads on! There's also a comp/comp for you to enter too. (See page 60). So, down to the March issue. Part one of Jim Norris's 'Disk Files', (a rare find!). Debug routines coded, Model 16 roundtable and servicing old hardware from Ken Brookner. Latest re-engineering details from Pascal Holdry. There's a one-liner from E.T. Fonehume just for Scrabble fans. Ian Mavric has articles on M3 video board repairs, reviews the Model 12 and looks forward to Tandy Assembly 2025. Randy Kindig interviews Don French and Steve Leininger. And finally, Vince Otten completes his Software Tools series with episode 7 and has details of a new series featuring Dr. David Lien's book, from back in the day, 'it's easier than you think'. And of course, there's all our regular features too.

You can download it from http://www.fabsitesuk.com/tandy/trs8bit1901.pdf

Issue Information:

Table of Contents:

I found some random CINTUG newsletters in a binder while cleaning out some TRS-80 stuff.

Title: CINTUG Basic IO Newsletter
Publisher: CINTUG
Year: 1979
Size: 11,340,563
Pages: 4
Notes: [1979-09]

Title: CINTUG Basic IO Newsletter
Publisher: CINTUG
Year: 1979
Size: 8,950,291
Pages: 5
Notes: [1979-11]

Title: CINTUG Basic IO Newsletter
Publisher: CINTUG
Year: 1979
Size: 6,883,555
Pages: 4
Notes: [1979-12]

Vernon Hester had previously written up (twice now, actually) a breakdown of ROM bugs he found while developing SuperBASIC. I had reached out to him for clarity on a few, and he got back to me on most. While I was holding off until I heard back on the rest, recent Facebook activity about a ROM Bug led me to conclude I should probably announce and add the page.

So ... if you would like to see the bugs he found, head on over to the ROM Errors page, with all but 1 duplicated.

Alistair MacMillan has 4 Model III's available for free for local pickup in Norwich, Norfolk.

He advises that were in a garage for a very long time and are as-is. From looking at them, he sees a couple of keys missing and there is a crack in one casing but other than that they seem to look ok. He has NOT powered them on.

If interested, and you can do local pickup, please contact me.

If you are looking for TRS-80 parts, such as matching (silver) paint, or replacement ROMs, or composite video cables, visit Tuc's Workbench at https://shop.tucs-workbench.com/.

Roger Murley / BYTESHiFT has a developed a recreation of the 26-1145 RS-232 interface board for the Model I

They are available for sale to those who wish to purchase one, or for those who like to build, the Gerbers, schematics, BOM, and KiCAD source files are available on GitHub.

Roger's design replicates the operation of the original board, ensuring compatibility with existing Model I software. Hardware-wise, he reports a few differences:

• SMT components are used wherever possible, to minimize cost
• Sense switch (DIP switch configuration) functionality is removed, so that the interface must be configured via software
• The TERM/COMM switch has been removed. The unit is configured in TERM (DTE) mode, and an external null-modem adapter must be used if operation as a DCE device is required.
• IC selection eliminated the need for +12/-12/-5 supply rails. +5V is the only supply needed

More info can be found at: https://byteshiftmusic.com/trs-80-model-i-rs-232-interface-re-creation/

TRS8Bit - Vol 19, No. 2

You can download it from https://www.fabsitesuk.com/tandy/trs8bit1902.pdf

Issue Information

Table Of Contents

George and Peter Phillips have updated their awesome TRS80GP emulator to v2.5.5. TRS-80 Model I/III/4-related changes are:

New Functions/Updates

• Debug -> File Utility window to examine and manipulate disk files.
• Scripting commands to control TRS-80 and UI. http://48k.ca/trs80gp.html#script
• Add your own commands to Custom menu with -menu
• Run commands at boot with -cmd
• Run commands along with with automatic input using -icmd
• Can pass arguments to endpoints: -p [ :mx70 -mute ]
• Motorola S-record file loading.
• Paste modes for injecting text on unsupported operating systems + programs.
• Added "-ib file" to run trs80gp script commands from a file.
• Added "-ifr file" to paste in a file with no line ending translation.
• Direct loaded BASIC programs can have multiple-line lines.
• Bus tracing can be limited to address ranges with -tr low:high,l2:h2
• Output registers to bus trace with -trpr A,HL or similar
• -cix option to turn off warning when cassette I/O seen and interrupts enabled.
• MX-70 can automatically pause at the end of every page.
• MX-70 tractor feed and perforations can be turned off.
• Add "save image" to printer window in Windows.
• Add Cassette to Device Viewer.

Bug Fixes

• Keyboard auto de-turbo now works on linux and mac.
• Serial port, printer and other dialogs have explicit enable checkbox.
• Fix linux crash when resizing window in turbo mode.
• Fix linux crash when media key like "pause" or "next track" pressed.
• Fix crash/emulation errors when examining active HFE disk images in Disk Viewer.
• Fix crash formatting single-density only DMK files as double density.
• "Typing" keyboard layout (-kl typ) better for Level 1, TRSDOS 2.3, CP/M input.
• Keyboard layout and ghosting now remembered as user preferences.
• Input system (-i flags) timing more consistent and useful.
• Loading symbols with -ls still allows boot into DOS.
• Symbols now appear in profiler output.
• Copy screen to clipboard sometimes failed in graphics-only mode under Windows.
• Trim trailing spaces and blank lines when copying text screen.
• Pasting to Tandy 10 faster and more reliable.
• MX-70 reset puts printer into default mode; cold restart drops pages.
• MX-70 no longer gets bad line height if high bit set in size.
• Stop -turbo from skipping renders; it was triggering legacy code.
• On Windows sub-processes like from -p :mx70 don't steal the focus.
• IMD/JV3 with CRC errors now report those errors to the FDC.
• Blank double-sided diskette images moved to Other submenu to reduce clutter.

You can download the emulator from their site at http://48k.ca/trs80gp.html.

Mloewen has provided some missing manuals!

Title: Micro-Courier v1.00.00
Publisher: Microcom Inc-Radio Shack
Year: 1982
Size: 7,021,857
Pages: 104
Notes: [M3][26-1589]

Title: Orchestra-80
Publisher: Jon Bokelman-Software Affair
Year: 1980
Size: 2186295
Pages: 44

Title: Teleterm Terminal Emulator System
Publisher: Telexpress Inc
Year: 1983
Size: 7436278
Pages: 198

Stuart Feldhammer has found a tape containing an issue of the fabled ASCII Magazine.

You can see him review/play the tape at https://www.youtube.com/watch?v=ncvzz7zP-d0

Matthew Reed wrote in to let me know of his brother's, Mark, passing.

Mark, author of the popular TRS-80 text editor ED-IT, as well as the Utility Disks sold by Computer News 80, and many articles about the TRS-80 for multiple publications, passed away on April 20, 2025.

You can download all of Mark's software.

Matthew Reed, who has done so much for the TRS-80 community, including writing quite a few of the most important programs in TRS-80 emulation, has taken seriously ill and has decided to make all of the versions of his software which previously was subject to paid registration to unlock all their features, freely available in their fully registered forms.

• Model 4 Emulator v1.0B for MSDOS.
  Instructions for use can be found on the manual page.
• Model I/III Emulator v1.0B for MSDOS.
  Instructions for use can be found on the manual page.

• TRS32 Model I/III/4 Emulator v1.28 for Windows.
  Instructions for use can be found on the manual page.

• Z80Asm v1.26 for Windows.
  instructions for use can be found on the manual page.


Thank you so much Matthew!

The next Trash Talk Live is on Saturday July 5th at 9pm Eastern! I hope to see all of you there!

Over the weekend I licensed ABBYY Finereader 16 and ran all 102 issues of 80 Microcomputing through it. While I am surprised at some bugs that seem to have survived 16 iterations of the program to make themselves known almost immediately, it has allowed me to leverage the dtSearch indexing software to help augment the graphic parts of the archive, mostly adding missing blurbs and ads, although also helping to correct some author errors.

The workflow is that I do an archive search for program whose author is known but which doesn't have an ad. I then use dtSearch to try to see if they advertised in 80 Microcomputing. If so, I use GhostScript (command line) to extract to the page from the 80 Microcomputing to TIFF and edit accordingly.

While not perfect, it helped.

I have finished going through the OCR'd 80 Microcomputing magazines looking for advertisements which were missing from the search results. All in all, 483 more advertisements have been added.

Rick Morris recently had his Model III's power supply go poof. He was kind enough to let me know that recap kits can be found at https://console5.com/store/tandy-radio-shack-trs-80-model-3-4-power-supply-cap-kit-astec-aa11320.html

Doug R was kind enough to provide two of the Radio Shack Technician Series bulletins:

Title: Radio Shack Technician Series - Diagnostics - Dynamic Memory Test
Publisher: Radio Shack
Year: 19xx
Size: 1,103,566
Pages: 16
NOTES: Model I-III Memory Diagnostics Program

Title: Radio Shack Technician Series - Diagnostics - FDCALCG 1
Publisher: Radio Shack
Year: 19xx
Size: 1,141,870
Pages: 14
NOTES: Model I FDC Alignment Program

Doug R was kind enough to provide some more publications and documents:

Title: Diagnostic and Burn In Tandy Drive Controller TDC 3
Publisher: Radio Shack
Year: 1981
Size: 2,909,023
Pages: 19

Title: Radio Shack Technician Series - Diagnostics - Model I and III Tandy Drive Controller
Publisher: Tandy
Year: 1982
Size: 2,908,586
Pages: 38

Title: Technical Education Series - Floppy Drive Training Workbook
Publisher: Tandy Corporation
Year: 1986
Size: 6,680,314
Pages: 72

Title: Western Digital Series I Hard Disk Driver
Publisher: Watt Breeze QSD
Year: 1983
Size: 641,624
Pages: 6

Title: Using a Single Hard Drive with Two Operating Systems
Publisher: Powersoft Products
Year: 1984
Size: 366,038
Pages: 3

Andrew Myers has written a Model III BASIC Game called Boozer. You basically move your player around the screen to get the beer and avoid cops, but the player gets harder to control the more beers it gets!

You can download that software now.

David S found the BASIC COMPUTER GAMES Vol 1 (TRS-80 Edition) for sale and kindly drop shipped it straight to me. Since Dave Ahl had previously released all his work (and all Creative Computing work), you can download it by clicking below!

Title: Basic Computer Games Volume I TRS-80 Edition
Publisher: David Ahl - Creative Computing
Year: 1979
Size: 36,612,228
Pages: 194
OCRed: Yes

Peter Philips was kind enough to point out some issues with the scan. While my original did not have pages 37 or 38, the errors he pointed out on pages 11, 60, 61, 124, 132, 133, and 134 have been corrected

If you previously downloaded the book, please re-download it.

Title: Basic Computer Games Volume I TRS-80 Edition
Publisher: David Ahl - Creative Computing
Year: 1979
Size: 36,612,228
Pages: 194
OCRed: Yes

By the way, the source book I had was completely water stained and in awful shape, so I am not surprised it was missing a page.

Jean-Francois DEL NERO, author of the HxC Floppy Emulator software, has let me know that the bug which had sometimes affected creating DMK images has been fixed! If you are using the most recent version and still experience a conversion error, please reach out.

I am sorry to announce that Matthew Reed has passed away. Matthew had done so much for the TRS-80 community, and for me personally, that this is a huge loss.

Matthew had previously made all of his "registered" software free and ensured that 100% of his source code was passed into good hands, so nothing there is lost.

His two TRS-80 related domains, www.TRS-80.org and www.TRS-80Emulators.com have now been registered to me, and I am currently hosting their prior content, which he had carefully converted his wordpress to HTML so that I could just upload it once he passed away.

An annoucement can be found at https://www.richlandsource.com/2025/08/20/matthew-reed/

Nicole Snapp-Holloway, daughter of Bob Snapp, has OK'd making all Snappware software and manuals available for download. Those links are now all live. Thank you, Nicole!

Dusty was kind enough to send over the User's Manual for the Programmable Sound Generator board for the TRS-80 Model I made by LFH Associates.

Thanks, Dusty!

Title: Programmable Sound Generator Board Users Manual
Publisher: LFH Associates Ltd
Year: 19xx
Size: 1,144,041
Pages: 12
OCRed: Yes

Jens Guenther's SDLTRS2 has been updated to v1.2.33. The changelog from v1.2.32 is:

• Added Solid State Disk (RAM-Disk) for Aster CT-80.
• Added character set for Aster CT-80 CP/M.
• Added debugger command to show hard disk controller state.
• Added debugger commands to fill and move memory.
• Added support for 8 Disk Drives (TCS SpeedMaster/Genie IIs/IIIs).
• Added function to copy the emulator screen to printer file.
• Fixed Aster CT-80 emulation to run CP/M (thanks to Wim Nelis).
• Fixed CP/M utilities (reported by Wim Nelis).
• Fixed some bugs and internal improvements.

You can find his site and downloads at https://gitlab.com/jengun/sdltrs.

The Australian TRS-80 Microcomputer News page has been updated to include Volumes 3, 4, and some of 5.

Thank you Gonk23 for the heads up and the issues!

George Phillips was kind enough to point me to a dump of the Yahoo TRS-80 groups from Archive.Org. I hope to go through it and see if anything is worth adding.

For now, here are some manuals which were turned into HTML, which I turned into PDF's

Title: Grand Prix 80
Publisher: Rick Maurice - Melbourne House
Year: 1982
Size: 331,315
Pages: 3
OCRed: No

Title: Martian Patrol
Publisher: Rick Maurice - Melbourne House
Year: 1982
Size: 469,517
Pages: 3
OCRed: No

Title: Space Attack
Publisher: Clifford Abrahams - Melbourne House
Year: 1982
Size: 453,035
Pages: 3
OCRed: No

Title: Wild West
Publisher: Clifford Abrahams - Melbourne House
Year: 1982
Size: 428,854
Pages: 3
OCRed: No

Title: Air Raid
Publisher: Small System Software
Year: 19xx
Size: 213,178
Pages: 3
NOTES: HTML to PDF

Title: Airmail Pilot
Publisher: Instant Software
Year: 19xx
Size: 355,333
Pages: 1
NOTES: HTML to PDF

Title: Ball Turret Gunner
Publisher: Instant Software
Year: 19xx
Size: 414,985
Pages: 5
NOTES: HTML to PDF

Title: House of Thirty Gables
Publisher: Bill Miller - Instant Software
Year: 19xx
Size: 259,374
Pages: 2
NOTES: IS0219R / HTML to PDF

Title: Oil Tycoon
Publisher: Instant Software
Year: 1979
Size: 662,952
Pages: 6
NOTES: IS0023R / HTML to PDF

Title: Packer
Publisher: Cottage Software
Year: 1979
Size: 213,589
Pages: 4
NOTES: HTML to PDF

Title: Pinball
Publisher: John Allen - Acorn
Year: 1980
Size: 249,228
Pages: 3
NOTES: HTML to PDF

Title: Slag
Publisher: Stewart Eastman - Adventure International
Year: 1980
Size: 562,464
Pages: 4
NOTES: HTML to PDF

Title: Space Invasion
Publisher: Author Unknown
Year: 19xx
Size: 192,068
Pages: 1
NOTES: HTML to PDF

... and some hardware manuals

Title: Aerocomp Disk Drive Installation Hint Sheet
Publisher: Aerocomp
Year: 19xx
Size: 1,111,760
Pages: 4
OCRed: Yes

Title: Aerocomp Model III and Model 4 Floppy Disk Controller Installation Instructions
Publisher: Aerocomp
Year: 19xx
Size: 1,494,066
Pages: 8
OCRed: Yes

Title: Network Controller 3 Operation Guide
Publisher: Radio Shack
Year: 1981
Size: 1,640,338
Pages: 12
NOTES: 26-1212

Title: Omikron Mapper Owners Manual
Publisher: Omikron
Year: 1980
Size: 2,207,388
Pages: 38

Title: TRS-80 Model I Preliminary Users Manual
Publisher: Radio Shack
Year: 19xx
Size: 822,707
Pages: 30
NOTES: 30 Pages

... and some catalogs

Title: Lichen Software Catalog
Publisher: Lichen Software
Year: 19xx
Size: 1,278,721
Pages: 21

Title: Mayday Center Catalog
Publisher: Mayday Software
Year: 19xx
Size: 281,824
Pages: 6

Title: Smallsystem Center Catalog
Publisher: Smallsystem Center
Year: 19xx
Size: 342,654
Pages: 6

... and some service manuals/procedures/schematics

Title: Expansion Interface Testing
Publisher: Radio Shack
Year: 1978
Size: 4,337,392
Pages: 10
NOTES: 1978-04-18 / Testing Procedures for Production Line Repair Technicans and Workflow Diagram

Title: TRS-80 Model I Prelimiary Service Manual
Publisher: Radio Shack
Year: 1977
Size: 5,198,347
Pages: 10
NOTES: 1977-11 / TRS-80 service manual consisting of only 10 pages

Title: TRS-80 Model I Preliminary Schematics Rev A
Publisher: Radio Shack
Year: 1977
Size: 15,798,791
Pages: 7
NOTES: 1977-09-22 / With Designer Handwritten Corrections

Title: TRS-80 Model I Preliminary Schematics Rev B
Publisher: Radio Shack
Year: 1977
Size: 13,808,839
Pages: 7
NOTES: 1977-09-22 / With Designer Handwritten Corrections

Title: TRS-80 Model I Testing Procedures
Publisher: Radio Shack
Year: 1977
Size: 5,785,046
Pages: 7
NOTES: 1977-09-09 / Testing Procedures For Tandy Production Line Repair Technicans

Title: Model 4 European Patent
Publisher: Radio Shack
Year: 1984
Size: 1,561,257
Pages: 62
OCRed: No
NOTES: PAL formulas

KiwiSinceBirth has updated his compilable source for the Model I. It is compilable with Telemark Assembler includes v1.2, v1.3, and EACA (selectable by #DEFINES). The following customizations are included:

• Enables the FreHD auto boot feature, i.e. the Auto boot ROM.
• Disable the use of memory mapped hardware at 37Exh, Floppy disk, Printer, etc. for machines where these peripherals are not needed (e.g. in a FreHD only system) and allows the use of the 2kb memory 3000h - 37FFh
• Set NMI (reset) as always perform a hard reset instead of returning to READY on non-DOS systems
• Disable Alpha character translation of letters A-Z,a-z to the values on range 00h to 1Fh. This is useful when a lower case mod is installed, but an alternate video driver has not been installed, or where the font rom on the machine has the alternate characters in the 00h 1Fh range (0471h)

You can find the Github at https://github.com/kiwisincebirth/TRS-80-ROMS>.

David S bought ANOTHER copy of the book, just to complete the missing pages 37-38. They have been integrated; so if you downloaded this previously, you should do it again.

Title: Basic Computer Games Volume I TRS-80 Edition
Publisher: David Ahl - Creative Computing
Year: 1979
Size: 36,612,228
Pages: 194
OCRed: Yes

Thank you, David.

Randy Kindig, of the Floppy Days Pocast, was kind enough to provide a scan of Twin Cities TRS-80 Users Group Vol 5 No 7.

Title: Twin Cities TRS-80 Users Group Vol 5 No 7
Publisher: TCTUG
Year: 1985
Size: 4,551,431
Pages: 10
NOTES: 1985-07

Title: Maxletter Issue 9
Publisher: Lobo Systems
Year: 1987
Size: 2,049,682
Pages: 6
NOTES: 1984-August

Thank you, Randy.

Randy Kindig, of the Floppy Days Pocast, was kind enough to provide a scan of Twin Cities TRS-80 Users Group Vol 5 No 7.

Title: Twin Cities TRS-80 Users Group Vol 5 No 7
Publisher: TCTUG
Year: 1985
Size: 4,551,431
Pages: 10
NOTES: 1985-07

Title: Maxletter Issue 9
Publisher: Lobo Systems
Year: 1987
Size: 2,049,682
Pages: 6
NOTES: 1984-August

Thank you, Randy.

TRS8Bit - Vol 19, No. 3

Dusty writes:

In this edition, Ian Mavric has the final details for the September Tandy Assembly, asks "what now" when you've bought a Model 2000, and has a review of the recent VCF-SW he attended. Vince Otten continues with part 3 of his fantastic series "Power of the ROM", and reviews the language, APL. (This was available for the M1!). E.T. Fonehume provides a one-liner BASIC program to suit the requirements of modern-day passwords. There's more development in 'News from France' from Pascal Holdry. Egoitz Campo sends in a review of the recent TRS-80 Basque Tournament. It seems LINUX is having a birthday. We're asking if you have any ideas for the 2026 competitions. There's a sad Obit. for Matthew Reed. A quick check on the U.K.'s Ebay bargains, a 'just for fun' maze puzzle and finally, a M1 upgrade I came across while 'Surfin the Net' (looks fantastic!).

You can download it from https://www.fabsitesuk.com/tandy/trs8bit1902.pdf

I turned Claude.AI on my three search pages and let it update them to a modern look as well as to handle responsivity in the results pages.

• Software Search
• Magazine Search
• Catalog Search

Now they don't look or act as dated as the rest of the site does.

TandyAssembly 2025 happened this weekend and they were lightning quick on getting some of the talks online.

Model I Version

Model III Version

Michael Wessel and Mark Pruden have developed X-MEM/80, a 512 KB paged memory expansion for the TRS-80 Model 1 and Model III.

According to them:

No permanent modifications are required for installation. The Model 1 version is entirely external (via expansion port edge connector), and the Model III version simply plugs into the existing Z80 socket on the Model III motherboard - the CPU needs to be relocated from the Model III motherboard onto the X-MEM/80 board, but it is already socketed. No motherboard modifications are required, but the RF shielding in the Model III needs to be removed.
Unlike previous memory expansions for the Model I (i.e., SuperMem), this is a minimally invasive memory expansion that does not require any soldering for installlation.
X-MMEM/80 is partially SuperMem compatible, as it allows to "bank" the upper 32 KBs (address range from 0x8000 to 0xFFFF) with the memory on the card.
A jumper allows configuration in two different modes - SuperMem and X-MEM/80 modes:

More info can be found at https://github.com/lambdamikel/x-mem-80

So far about 200 pages have been converted to the newer format, with about 100 more to go. Claude.ai has now instituted not only hourly caps but weekly caps, so this is very slow going.

Between Claude AI and Gemini Pro (but definitely not Gemini Flash), the web site has been updated to new CSS. I have moved prior news into the "old news" pages because WordPress would require me to update each news item individually otherwise.

You can see 2025 news below.

There might be broken CSS when I kill the old CSS. I still have work to do though. Since AI sessions can only be so long, each new session required me to feed in the CSS to date, and I instructed it to re-use as much CSS as it could. Despite that, over 650 new CSS definitions were created; so much for site consistency.

Well, the first pass of the AI conversion did an OK job, even if it took about a month due of token limits. The problem is that it created 1500 classes because of the number of sessions that had to be used. Instead of it being able to consistently review pages and apply consistent code, even when instructed to re-use old code, it didn't do a great job.

So I need to make another pass. I have developed, with AI's help, three main types of code sections - general, columnar, and images. As I move page to page, I have those codes updated as needed. This should bring consistency to the site.

Some of the things about the new design that I absolutely love, is that a simple CSS class added to a catalog entry, email address, or clickable image, just adds a note telling you what you can do with that. This is something I would have used JQUERY for in the past, but CSS3 is pretty awesome! Examples are the little caption on the pictures below; automatically added by CSS.

Anyway, the AI page pass left me with 1500+ CSS entries, and those need to get culled. Well, most of them. It turns out that the new search pages require 450 CSS entries! They are kind of beautiful, so I'm going to leave those alone.

For the rest of the pages, I had Gemini write some Visual BASIC Code to parse every html file, extract every class used, and come up with a display that would show me the class, the code, and the files which use it. I also had to have it let me know about dependencies after a particularly disasterous attempt to globally update the code.

This is a sample of the output.

Here, there is a class used by only 1 page. In this case, it's because its a typo. But putting that aside, it is my clue as to the next page to edit. I then go through and update the page to use the new classes.

Once that page (or pages) are done, I use WildEdit to search the entire tree for the class.

If it shows no changes made, then I can delete the CSS.

I also had a button prepared that would output the "good" and "bad" css. If I get tired of editing specific pages, but still want to make progress, I use WildEdit to find entries that are on the "bad" page. If there are no results, I can just strike that CSS entry.

So that's what's going on now ....

But as of this point, v1 CSS is pretty much gone, so if you see a page (or table) that is broken, let me know!

Update: Claimed

A site visitor (and very frequent contributor) has multiple Model I components that he would like to give away by local pickup only in the Norfolk, Nebraska area.

He lists:

• two monitors
• two expansion interfaces
• three keyboard units (one not working)
• a few floppy drives (condition unknown, but worked a few years ago)
• several DOS manuals, books, and newsletters

If you are interested in picking up that stuff, please contact me and I will pass on your interest.

KiwiSinceBirth has released v2.0a of his redesigned Model I motherboard. He reports the following changes:

This project is an upgraded / evolved TRS-80 Model 1 main board replacement. It was designed to provide a reliable, compact, and modern replacement, removing some limitations of the original 1970's product, while still remaining faithful to the original technology (i.e. no emulation)

v2.0a provides significant improvements in video, not only does it use dual port RAM for snow free video, but it changes the video sync generation circuit bringing back the picture adjustment controls not present in V1. Also supported is software switchable fonts, for alternate languages or other graphics. Other major features added to the board include an audio amplifier for a small speaker (which can be mounted on the board), Alpha Joystick port compatible with most software, and ability to mount a modern clock oscillator. Have added about 10 new config jumpers/settings in support of new features. V1 is still fully supported including a separate build guide. Not forgetting Supermem bank RAM and internal FreHD

>New Features

• Dual port video SRAM, reducing contention (snow) issues with shared CPU access.
• Onboard Audio amplifier utilising small class D module, with space for PCB speaker
• Alpha Joystick port with header to connect 9 Pin DB9 Connector
• Changed crystal oscillator to parallel resonant circuit based on 74HCU04 chip, which is pin compatible with a Full Can (DIP14) oscillator.
• New Video sync generation circuit, including Horizontal and Vertical Position.
• Improved support for RGBtoHDMI by exposing HSYNC on Video DIN socket
• Added Tim Halloran's no-chip VBLANK modification, for improved video updating.
• Added Jumper (JP16) to allow main Reset button to function as full CPU reset.
• Can configure either RAM or ROM to occupy the 12kB to 14kB address space in memory.
• Added support for EEPROM in circuit writing (requires software support).

Changed Features

• The Video DIN socket now has Jumper (JP19) to disable external power
• Added PCB reset button (SW11) to allow full reset during diagnostics
• CPU speedup offer fast speed as 5.3 (default 3.55) mhz via jumper (JP17)
• Added Power LED indicator (D1) near to the main power switch.
• Fixed issue with TEST signal immediately disconnecting CPU from BUS - Credit Marcel Erz
• Fixed Issue with Bus control for interrupt Mode 0 and 2 where external device places data on bus
• Added (back) software character set control (Port FF Bit 7), as per JP board.
• Changed meaning of SW10-SW13. Now ON => Logic 1, and OFF => 0 (rather than reverse)
• RAM is configurable from 48k (default) down to 16k for compatability with external RAM.

Minor Improvements

• Moved main 10.6Mhz oscillator to central location, shorter signal paths.
• CPU clock speed selector flip-flop (Z63a) clocked at slowest rate.
• JP10 (and related circuit) used for video frequency was removed.
• Inputs of spare gates are now tied to GND or VCC, with easy trace cuts for future use.
• Added resistor pull-ups on address, data, and control busses, for CMOS stability.
• Added resistor pull-ups on keyboard, prevent issues when no keyboard attached.
• Provided ability to use spare IO pins (CAS and MUX) on IO expansion.
• Moved main power switch (SW1) and socket (J11) closer to other ports, better clearance
• Added several M3 mounting holes for internal expansion board mounting
• Improved (more modern) footprints for C19, C70, Q1, Q2, CR4.
• Replaced several discrete resistors with small resistor packs.
• Fixed multiple issues with small via's and thermal reliefs on power rails
• Main power Capacitor C101 now has more space for horizontal mounting.
• Improved silkscreen for component identification, and configuration options
• Improved component identification in Bill of Materials
• Major improvement in the Schematic diagram quality.
• Many component designators have changed from V1, so some V1 docs may not be accurate
• Added testpoints to support 3 signals required by SuperMem
• Changed main power capacitor C11 to 470Uf after testing from MSly
• Changed main power switch to discharge C11 (using 100R R14) when switched off
• Keyboard resistor pack RN5 corrected to pull down keyboard data lines.
• Corrections to Bill of Materials, and silkscreen fixes and improvements.

You can find all the information, as well as downloads for the BOM and circuit board, at https://github.com/kiwisincebirth/TRS-80-MODEL-1-K/tree/main

The next TRS-80 Trash Talk live show is November 1, 2025 at 6:00PM Pacific Daylight Time / 3:00PM Eastern Daylight Time!

Larry Fosdick has come across a cache of DOSPlus News Information Centers. Thank you, Larry!

Title:DOSPlus News Information Center 82-01-02Publisher:Micro Systems SoftwareYear:1982Size:8,318,607Pages:20OCRed:Yes*Notes:Set 2

Title:DOSPlus News Information Center 82-05-06Publisher:Micro Systems SoftwareYear:1982Size:12,336,303Pages:36OCRed:Yes*Notes:Set 2

Title:DOSPlus News Information Center 82-07-08Publisher:Micro Systems SoftwareYear:1982Size:14,950,795Pages:36OCRed:Yes*Notes:Set 2

Title:DOSPlus News Information Center 82-09-10Publisher:Micro Systems SoftwareYear:1982Size:10,226,736Pages:40OCRed:Yes*Notes:Set 2

Title:DOSPlus News Information Center 83-SummerPublisher:Micro Systems SoftwareYear:1983Size:23,459,217Pages:43OCRed:Yes*Notes:Set 2

KiwiSinceBirth has posted his compilable source file for the Model III ROM

Main Features

• Fully Compilable Source Code for Model III Level 2 14KB ROMS
• Several optional patches have been included via #DEFINE
• Based on ROM A = 9639, ROM B = 407C, ROM C = 2EF8

Build Options

There are several DEFINE's that can be set in the code (very start) to enable certain features.

• #DEFINE VIDEO50 - Enable 50Hz Video Support (Affects RTC)
• #DEFINE FREHDBT - Enables the FreHD auto boot ROM feature, ie load fre HD at start
• #DEFINE BUGFIX27 - Fix Bug 27 - 06CCH - Basic Entry Point
• #DEFINE BUGFIX28 - Fix Bug 28 - 034BH - Stack Initialisation Problem
• #DEFINE BUGFIX30 - Fix Bug 30 - 034BH - 32 char Mode, Incompatible Model 1 code
• #DEFINE BUGFIX40 - Fix Bug 40 - 05D1H - Broken "RON" Printer Status Routine
• #DEFINE SIZE16K - Will pad the end of the rom with $FF to 16KB size. useful if want to append multiple ROM images for used in large 16K paged rom
• #DEFINE DONTEND - Disable .END directive if #INCLUDEing the source inside another file

Visit his site at https://github.com/kiwisincebirth/TRS-80-ROMS.

When Matthew Reed passed, and asked me to host his sites, he gave me wordpress pages converted to HTML. That was the way to do it, since WordPress works off of a bunch of PHP code on the back and and a large database - not easily movable.

The process of making that HTML usable, though, was challenging; particularly since the HTML was just a frozen moment-in-time of the WordPress, with all the stats bars ('most read articles', 'associated articles', etc) locked in place, and all pointing to directories instead of .html files.

Since we are all mortal, I thought about that and decided to convert TRS-80 away from WordPress. It will make maintaining site much easier, for sure.

The most significant improvement is in terms of screen width - no longer wedged into 800 pixels for no valid reason. The 3 search page results now also span the width, making things a lot less crushed. On the mobile side, those pages scroll, and most of the HTML seems to be working great on the smaller screens. Also, "Click to Enlarge", "Click to Download", and "Click to Email" are all inserted by CSS automatically so you know what clicking on something might afford.

If you come up with any 404 errors, or any really-off formatting, or have any usable suggestions, please let me know.

A new page for all available TRS-80 upgrades and add-ons as been added. The various associated information is still present wherever it is on the site, but this page attempts to consolidate all of the offerings. If there is any missing or incorrect information, please let me know. You can see the new page.

Also, I have updated the TRSDOS v1.3 Zaps page to include explanations as to what each patch does along with jumps into the various disassemblies.

Today was the first time I ran into what Ian has run into for a while ... unreadable Radio Shack brand disks. I previously had good luck with them, but today I received two different sets of disks to read. One was Radio Shack only and one was Radio Shack and Storage Media.

With almost no exceptions, I was unable to read the Radio Shack disks from both sets. I had thought a bunch of Storage Media disks were also bad, but upon trying to second set, it dawned on me to try reading without introducing any Radio Shack disks into the process. Once I did that, all Storage Media disks read without issue.

I wonder if we have hit some sort of magic timeframe whereby Radio Shacks are now no longer viable. I mean, its been over 40 years and its a miracle that any disks can be read ... but perhaps Radio Shack disks are now past their time?

I think the site redesign is now done. Some pages have had major rewrites (all thanks to AI) like the Missing Software page, and the search pages, but by this point all pages are using consistent CSS which has been minimized.

While I was at it, I tried to augment the magazine pages to all include the table of contents (where they existed).

If you still see any formatting errors or issues, let me know.

Thank you to everyone that has been reporting in with questions and issues!

And special thanks to Ven Reddy who pointed out that when I moved off of WordPress I lost the Site Search function. I personally consider the site too unwieldy and too hard to find anything, and I wrote it - so I can imagine what everyone else goes through. So the loss of site search was a big loss. The site search page is now present on the navbar as well.

If anyone has any better ideas as to how to organize the navigation or make it easier to find subpages and content, please let me know.

In other updates, I have been working on the disassembly pages trying to add more information to the input/output portions. Right now it's in the form of adding bit tables to show all the options and explanations within each comment. Also, as of last night, the disassemblies are "mobile friendly".

The Easter Egg page page has been updated with a reverse engineering of Randy Cook's secret screen from TRSDOS v2.x. Thanks to George Philips and absolutely no thanks to Gemini who halucinated an elaborate routine that didn't exist!

Amardeep Chana has written up step-by-step instructions to modify a Model I to run much cooler and more reliably. It involves modifying the system to no longer need the +/-12V to power the RAM, focusing solely on 5V.

The commented/explained disassembly of BACKUP/CMD and TAPEDISK/CMD from Model I TRSDOS v2.3 haves been added.

You can download it from http://TRS-80.org.uk/

Issue Information:

Issue Summary:

George Phillips discusses Bart Jeroen Hemstra’s winning competition entry. Ian Mavric shows how to downgrade a Model 1 to Level 1, has a report of the 2025 Tandy Assembly and takes a look at Model 2000 hardware add-ons with part 2 of his series. Vince Otten has part 4 of his ‘Power of the ROM’ articles and also looks at early PASCAL compilers for the Model 1. E.T. Fonehume has a BASIC one-liner screen-saver, for a seasonal snowflake. Pascal Holdry has news of his latest, fantastic, re-engineering hardware tasks. There’s a quick look back to the early 1980’s in ‘The Way We Were’. Also, there’s a round-up of a few U.K. Ebay bargains, a maze puzzle just for fun and finally, ‘Surfin the Net’ comes up with an ‘all new’ Model 1 motherboard. 84 pages of pure Tandy joy!

Table of Contents

I wanted to make it easier for people to be able to refer to specific portions of the site, so I have added CSS and Javascript that will put a little clipboard up on headers. If you click the clipboard, the URL for that specific header will be copied to your clipboard. Thank you Gemini for the code!

Lawrence Kesteloot has updated his TRS80Tool to v2.8.2. Changelog is:

Fix a bug in the display of file sizes in the dir command.

Lawrence has also updated his online TRS-80 Assembly Language IDE, found at https://www.my-trs-80.com/ide/. Changelog is:

• The “File” menu has a new “Play Cassette Audio” command to play the assembled program as an audio sound. Connect your computer’s audio to a real machine and use the SYSTEM BASIC command to start the load.
• The “Edit” menu has a new “Auto-complete on Tab” option to set whether the Tab key accepts the auto-completion suggestion.
• The “View” menu has a new “Show Statistics” option that displays code and data statistics for the whole program and the current selection.
• The “View” menu has a new “Screen Size” option to change the size of the screen, in case you want more room for the text editor.
• The “Debug” menu has a new “Inspectors” sub-menu to show a Floppy Disk Controller inspector.
• The “Help” menu has a new “About” option to show the IDE’s version and release date.

If you sent in a disk request which was not processed, you have my apologies. As part of the site redesign, I seem to have dropped the perl script which actually sent the disk request form in! If you emailed me, it was processed; but if you silently sent in the form and that's it ... it wasn't. I have fixed the form so it should submit. If you requested disks and did not get them, please fill out the form again.

Jens Guenther has updated his Windows/Linux fork of the SDLTRS Emulator to v1.2.34

Changelog:

• Added Holmes VID-80 (VX-3) support for TRS-80 Model III.
• Added 48 KB extended memory for Holmes VID-80 (VX-3).
• Added 256/512/768/1024 KB for Alpha Technology SuperMem.
• Added X-MEM/80 (Michael Wessel) 16K page Model I memory extension.
• Added printer type for text only output.
• Fixed LNW80 Model II banking and 80x24 text mode support.
• Fixed some bugs and internal improvements.

The official site can be found at https://gitlab.com/jengun/sdltrs

Shawn Sijnstra has released v18 of this Infocom Adventure Interpreter line. His changelog:

• Code optimisation for speed and size including init, bwdcopy, fwdcopy, tokenize, inibuf, find_word, next_token, llf
• Rewrote all core code to assume auto-increment of ZPC to improve speed and size
• Bugfix: handle auto wrapped line followed by immediate line feed
• Additional space freed to allow for more game cache
• Memory map reshuffled to reduce disk size. CP/M version 900+ bytes smaller freeing up extra disk space

The official site can be found at https://gitlab.com/sijnstra1

NEWDOS/80 v2.0 for the Model I has been disassembled, with most of the heavy lifting done by Claude AI, with help from Gemini and Grok. They all definitely have their strengths and weakenesses.

I have also created a main-menu entry for all disassemblies, to make them easier to get to.

TRSDOS v1.3 and 2.3 have been disassembled and commented.

Happy New Year everyone!

To make linking easier, I have added clipboard icons to the Hardware, Software, and Service Manual pages.

The SSL certificate for www.trs-80.org has been purchased and applied, so related security warnings should have stopped.

Paul Hopkins was kind enough to send over Key Commander, one of the known missing files!

Thank you, Paul!

Ian Mavric was kind enough to send over Ham Package I and Electronics I, both by Instant Software, and both on the missing software list! Thank you, Ian!

The next TRS-80 Trash Talk live show is January 16, 2026 at 6:00PM Pacific Daylight Time / 9:00PM Eastern Daylight Time!

You can watch on the TRS-80 Trash Talk channel: https://www.youtube.com/channel/UCXkGugvdCkpkMDylVQb9gfg

If you want to participate in the live zoom session, reach out to trs80trashtalk at gmail dot com for information.

George and Peter Phillips have updated their awesome TRS80GP emulator to v2.5.6. Changes are:

New Features:

• Added "feed" and "delay" script commands.
• Backtrace now annotated with labels when they are available.
• Directly loaded Model 1 and 3 BASIC programs now convert ^ to [
• Disk viewer can be used to modify sector data.
• Gendon character ROM available for model 1 via -charrom :gendon
• Green Thumb emulation.
• IMD disk image saves blank tracks as empty records, allows HxC 0x80 modes.
• Implemented "load" and "run" script commands.
• Printer menu options for 80 and 132 column fixed-width printing.
• Supermem (-mem supermem) and X-MEM/80 support for Model 1 (-mem xmem80).

Bug Fixes:

• 6809 subtract/compare operations no longer modify the half-carry flag.
• Add delay to FDC Restore to fix Arranger II adding disks.
• Disk viewer/disk summary works correctly for hard drives using sector ID ranges 1..n
• Fixed Mac context menu
• Fixed Mac debug disassembly window for some processors.
• Improved IM 0 mode for Model I allowing TPM to format a diskette.
• Memory views no longer wrap around to address 0; it was too confusing.
• Model 12, etc. back to immediately reacting to bank swap (port A8H).
• RS-232 transmit interrupt asserted at when RS-232 reset.
• Use only 4 bits of FreHD commands like the real FreHD.

You can download it at http://48k.ca/trs80gp.html

KiwiSinceBirth has posted updates to his compilable source file for the Model I/III ROM

He has a traditional Model I Level 2 BASIC ROM and Model III Level 2 BASIC ROM which have comments and which can be compiled into a workable ROM. His source differs from a standard disassembly in the following ways

• Replaced all disassembler generated labels with meaningful labels.
• Ensured all jumps (JR and JP) reference valid code labels.
• Replaced all 3xxxH hardware references with .EQU definitions.
• Replaced all 4xxxH buffer references with .EQU definitions.
• Replaced all xxH byte references with appropriate decimal or ascii values, and/or .EQU definitions.
• Replaced all generated op-code with Byte .DB .DW definitions for DataTables/Text/Constants/Etc
• Added code documentation from various sources at the code block / function level.
• Replaced incorrect op-codes, where Better Else "Trick" was used.

These ROMs can also be somewhat customized as follows:

He has also developed an enhanced ROM for both machines which have slightly broken compatibility, but which otherwise include new support, features, and some bug fixes

To make room for all this, cassette support has been removed.

Additionally, you can now download pre-built binary images for most common configurations. There are 16 variants. Hr did this to make it easier to use, no assembly required, no defines to understand, just choose the ROM that makes sense. It also means the vanilla configurations can be compared against official roms, to check for binary compatibility. This build process is automated by GITHub anytime a change is made, it will assemble and publish a new release.

• Dick Smith System 80 (Official)
• Dick Smith System 80 FreHd Patched
• Dick Smith System 80 Patched
• Model I Rev 1.2 (Official)
• Model I Rev 1.3 - FreHD Patched
• Model I Rev 1.3 - Patched
• Model I Rev 1.3 (Official)
• Model I Rev 1.4 (Enhanced 50Hz)
• Model I Rev 1.4 (Enhanced)
• Model I Rev 1.4 (Enhanced)
• Model III - FreHd Patched
• Model III - FreHd Patched 50Hz
• Model III - Patched
• Model III - Patched 50Hz
• Model III (Official)
• System 80 Rev 1.4 (Enhanced)

Visit his site at https://github.com/kiwisincebirth/TRS-80-ROMS

• Tuc has TRS-IO++ fully assembled boards in stock and ready for immediate shipping. Visit https://shop.tucs-workbench.com/products/trs-io for more information.

---

• Dusty2050 has TRS-80 Model I keyboards based on MX keys for sale. Visit https://www.ebay.com/sch/i.html?_ssn=DustysVintageWorkshop ebay store.

---

• KiwiSinceBirth has pointed out that his Model I and Model III updated ROMs come with 16 pre-built configurations as well as source code, for those daunted by the compilation process
  You can find them at https://github.com/kiwisincebirth/TRS-80-ROMS

---

• Irwin Burton has written two new TRS-80 Model III programs - NAMEIT and PWD. NameIt allows for all characters to be in a LDOS disk label and PWD (like the unix command) will give you a quick update of what disk is mounted in a drive number. Source is included.

---

• The next TRS-80 Trash Talk (#47!) is scheduled for Saturday, February 21, 2026 at 6:00PM Pacific Daylight Time.

GrumpyX has kindly provide a whole bunch of Radio Shack related scans ...

Title:Product Flyer - Carry In Service ContractPublisher:Radio ShackYear:1979Size:61,313Pages:1OCRed:Yes

Title:Product Flyer - Cobol Development System Model IIPublisher:Radio ShackYear:19xxSize:209,970Pages:4OCRed:YesNotes:26-4703

Title:Product Flyer - Fortran Development System Model IIPublisher:Radio ShackYear:19xxSize:247,816Pages:4OCRed:YesNotes:26-4701

Title:Product Flyer - Model II LeasingPublisher:A and A FinancialYear:19xxSize:827,162Pages:2OCRed:Yes

Title:Product Flyer - Network IPublisher:Radio ShackYear:19xxSize:433,883Pages:2OCRed:YesNotes:26-1210

Title:Radio Shack TRS-80 Software LibraryPublisher:Radio ShackYear:19xxSize:57,940Pages:1OCRed:YesNotes:Introduction to BASIC Part I / 26-2150

Title:Radio Shack TRS-80 Update 1978-02Publisher:TandyYear:1978Size:475,923Pages:4OCRed:YesNotes:07-05-1978

Title:Radio Shack TRS-80 Update 1978-03Publisher:TandyYear:1978Size:239,398Pages:2OCRed:YesNotes:08-10-1978

Title:Radio Shack TRS-80 Update 1979-09Publisher:TandyYear:1979Size:533,328Pages:4OCRed:YesNotes:09-28-1979

Title:Radio Shack TRS-80 Update 1979-10Publisher:TandyYear:1979Size:205,569Pages:2OCRed:YesNotes:10-16-1979

Title:Radio Shack TRS-80 Update 1979-11Publisher:TandyYear:1979Size:206,632Pages:2OCRed:YesNotes:10-31-1979

Title:Radio Shack TRS-80 Update 1979-12Publisher:TandyYear:1979Size:473,357Pages:6OCRed:YesNotes:11-15-1979

Title:Radio Shack TRS-80 Update 1979-13Publisher:TandyYear:1979Size:210,533Pages:2OCRed:YesNotes:12-03-1979

Title:Radio Shack TRS-80 Update 1979-14Publisher:TandyYear:1979Size:310,611Pages:4OCRed:YesNotes:12-31-1979

Title:Radio Shack TRS-80 Update 1980-04Publisher:TandyYear:1980Size:147,613Pages:2OCRed:YesNotes:02-01-1980

Title:Radio Shack TRS-80 Update 1980-05Publisher:TandyYear:1980Size:83,878Pages:1OCRed:YesNotes:02-04-1980

Title:Radio Shack TRS-80 Update 1980-09Publisher:TandyYear:1980Size:372,188Pages:4OCRed:YesNotes:04-02-1980

Title:Radio Shack TRS-80 Update 1980-10Publisher:TandyYear:1980Size:285,200Pages:4OCRed:YesNotes:04-07-1980

Title:Radio Shack TRS-80 Update 1980-11Publisher:TandyYear:1980Size:337,548Pages:4OCRed:YesNotes:04-29-1980

Title:Radio Shack TRS-80 Update 1980-13Publisher:TandyYear:1980Size:386,403Pages:4OCRed:YesNotes:06-27-1980

Title:Radio Shack TRS-80 Update 1980-14Publisher:TandyYear:1980Size:341,911Pages:4OCRed:YesNotes:07-07-1980

Title:Radio Shack TRS-80 Update 1980-16Publisher:TandyYear:1980Size:611,867Pages:8OCRed:YesNotes:09-01-1980

Title:Radio Shack TRS-80 Update 1980-17Publisher:TandyYear:1980Size:378,338Pages:4OCRed:YesNotes:09-12-1980

Title:Radio Shack TRS-80 Update 1980-18Publisher:TandyYear:1980Size:595,581Pages:8OCRed:YesNotes:10-09-1980

Title:Radio Shack TRS-80 Update 1980-20Publisher:TandyYear:1980Size:338,670Pages:4OCRed:YesNotes:11-26-1980

Title:Radio Shack TRS-80 Update 1980-22Publisher:TandyYear:1980Size:722,752Pages:8OCRed:YesNotes:12-24-1980

Title:Radio Shack TRS-80 Update 1981-01Publisher:TandyYear:1981Size:312,942Pages:4OCRed:YesNotes:01-14-1981

Title:Radio Shack TRS-80 Update 1981-02Publisher:TandyYear:1981Size:166,877Pages:2OCRed:YesNotes:01-21-1981

Title:Radio Shack TRS-80 Update 1981-03Publisher:TandyYear:1981Size:358,883Pages:4OCRed:YesNotes:02-03-1981

Title:Radio Shack TRS-80 Update 1981-06Publisher:TandyYear:1981Size:373,943Pages:4OCRed:YesNotes:04-01-1981

Title:Radio Shack TRS-80 Update 1981-07Publisher:TandyYear:1981Size:357,870Pages:4OCRed:YesNotes:04-23-1981

Title:Radio Shack TRS-80 Update 1981-08Publisher:TandyYear:1981Size:379,310Pages:4OCRed:YesNotes:05-08-1981

Title:Radio Shack TRS-80 Update 1981-09Publisher:TandyYear:1981Size:378,102Pages:4OCRed:YesNotes:05-18-1981

Title:Radio Shack TRS-80 Update 1981-10Publisher:TandyYear:1981Size:329,809Pages:4OCRed:YesNotes:06-03-1981

Title:Radio Shack TRS-80 Update 1981-11Publisher:TandyYear:1981Size:82,093Pages:2OCRed:YesNotes:06-15-1981

Title:Radio Shack TRS-80 Update 1981-12Publisher:TandyYear:1981Size:60,460Pages:2OCRed:YesNotes:06-24-1981

Title:Radio Shack TRS-80 Update 1981-13Publisher:TandyYear:1981Size:179,064Pages:2OCRed:YesNotes:06-29-1981

Title:Radio Shack TRS-80 Update 1981-14Publisher:TandyYear:1981Size:135,527Pages:2OCRed:YesNotes:07-08-1981

Title:Radio Shack TRS-80 Update 1981-18Publisher:TandyYear:1981Size:181,324Pages:2OCRed:YesNotes:08-12-1981

Title:Radio Shack TRS-80 Update 1981-21Publisher:TandyYear:1981Size:191,934Pages:2OCRed:YesNotes:09-08-1981

Title:Radio Shack TRS-80 Update 1981-22Publisher:TandyYear:1981Size:212,757Pages:2OCRed:YesNotes:09-29-1981

Title:Radio Shack TRS-80 Update 1981-23Publisher:TandyYear:1981Size:212,395Pages:2OCRed:YesNotes:10-09-1981

Title:Radio Shack TRS-80 Update 1981-27Publisher:TandyYear:1981Size:211,238Pages:2OCRed:YesNotes:11-06-1981

Title:Radio Shack TRS-80 Update 1981-31Publisher:TandyYear:1981Size:228,069Pages:2OCRed:YesNotes:12-18-1981

Title:Radio Shack TRS-80 Update 1982-01Publisher:TandyYear:1982Size:267,637Pages:2OCRed:YesNotes:01-07-1982

Title:Radio Shack TRS-80 Update 1982-02Publisher:TandyYear:1982Size:226,611Pages:2OCRed:YesNotes:01-21-1982

Title:Radio Shack TRS-80 Update 1982-03Publisher:TandyYear:1982Size:225,192Pages:2OCRed:YesNotes:02-22-1982

Title:Radio Shack TRS-80 Update 1982-04Publisher:TandyYear:1982Size:292,951Pages:3OCRed:YesNotes:03-08-1982

Title:Radio Shack TRS-80 Update 1982-05Publisher:TandyYear:1982Size:540,253Pages:5OCRed:YesNotes:04-06-1982

Title:Radio Shack TRS-80 Update 1982-06Publisher:TandyYear:1982Size:386,402Pages:4OCRed:YesNotes:04-27-1982

Title:Radio Shack TRS-80 Update 1982-07Publisher:TandyYear:1982Size:456,079Pages:4OCRed:YesNotes:05-24-1982

Title:Support Group ListPublisher:TandyYear:1983Size:203,572Pages:2OCRed:Yes

Title:Thank You for Tampa Computer ShowPublisher:TandyYear:1980Size:257,516Pages:1OCRed:Yes

Title:TRS-80 Merchandising Memo 81-09 [700 Series Software Items]Publisher:TandyYear:1981Size:99,584Pages:1OCRed:YesNotes:700 Series Software Items

Title:TRS-80 System Selection GuidePublisher:TandyYear:19xxSize:60,836Pages:1OCRed:Yes

GrumpyX has kindly provide an issue of the Popular Computing Newsletter

Title:Popular Computing NewsletterPublisher:Popular Computing IncYear:1978Size:1,062,862Pages:16OCRed:YesNotes:1978-12

Cris Peeters has kindly provided the following manuals in Dutch

Title:LS-DOS 6.3 Update for TRSDOS 6.2XPublisher:TandyYear:19xxSize:86,033,395Catalog:706-2292Pages:27OCRed:YesNotes:Dutch

Title:Model 4-4P Disk SystemPublisher:TandyYear:19xxSize:942,792,899Catalog:701-1069-1080Pages:510OCRed:YesNotes:Dutch

Ian Mavric was kind enough to send over some missing items! Thank you, Ian!

• BMON Basic Monitor v1.2
• BPA Basic Programming Assistant
• Life: BASIC Version
• Life: Machine Language Version
• Misosys Disassembler v1.2
• Skirmish-80
• Space Games 3
• Z80 Disassembler

Irwin has written two DiskDisk related programs. He writes:

CDD/CMD v2.0.0 is a little utilty to use with the DiskDisk utility from MISOSYS that allows us to emulate the MS-DOS CD command. I wanted to be able to change DiskDisks as easy as I change subdirectories on MS-DOS.
Usage: CDD [:dn] DDfilespec
Where DDfilespec is the name of the DiskDISK file you want to mount. and :dn is an optional drive number you want to use for that file. The default is :4.

RMD/CMD v2.0.0 allows for the DISABLE to disable not just a DiskDISK mounted at :4, but the user is now free to disable a DiskDISK no matter which drive it is mounted to.
Usage: RMD [:dn]

The next TRS-80 Trash Talk live show is TODAY, February 21, at 6:00PM Pacific Daylight Time / 9:00PM Eastern Daylight Time!

You can watch on the TRS-80 Trash Talk channel: https://www.youtube.com/channel/UCXkGugvdCkpkMDylVQb9gfg

If you want to participate in the live zoom session, reach out to trs80trashtalk at gmail dot com for information.

Jay Newirth has let me know that he has two new FreHD related products:

FreHD External Case Complete Kit (Includes FreHD)

FreHD External Case (Bare)

You can visit NewSoft at https://jaynewirth.wixsite.com/newsoft.

While it will take many weeks to get done, I have started the commented disassembly of NEWDOS/80 v2.0 for the Model III.

As of this posting, BOOT/SYS and SYS0/SYS-SYS8/SYS are done. You can find the main page.

SYS9/SYS and SYS14/SYS have been added. You can find the main page.

There is a nice writeup on Leaded Solder about a Model I found in the trash, and the efforts to bring it back to life.

You can find it at https://www.leadedsolder.com/2026/03/03/trs80-model-1-power-supply-case-fix.html

SYS15/SYS, SYS16/SYS, and SYS17/SYS have been added, which finishes the non-BASIC system modules. You can find the main page.

In this 88 page edition, the first of our 20th year, Patrick Bureau fixes an ASTEC PSU, E.T.Fonehume tries coding on a Model 1 with 2 BASIC one-liners. Ian Mavric has his quarterly T.A. update, continues with part 3 of his Tandy 2000 history and looks at the keyboards for the models 1,3 and 4. Vince Otten has part 5 of his series 'The Power of the ROM' and investigates an early implementation of LISP for the Model 1. Pascal Holdry has news of the New JFD-CP. Egoitz Campo has the results of his latest Basque TRS-80 tournament. And as always, there's our regular features 'Surfin the Net' and 'The Way We Were' together with a new quiz, 'Countdown'.

You can read more about it on the TRS8Bit Page and you can download it from http://TRS-80.org.uk/

Some site updates:

• Added Le Guepard and the PROF-80 to the Clones Page thanks to Pascal.
• Enabled a very simple "lazy load" on some graphic heavy page, including this one, to make them load faster
• Added a RSS feed (third party) to the site. Button is on the left.

• The little indicator as to whether a secton has been collapsed or expanded has been fixed.
• BASIC/CMD for NEWDOS/80 v2.0 for the Model III has been disassembled.

SYS10/SYS and SYS11/SYS have been added. You can find the main disassembled NEWDOS/80 v2.0 for the Model III page. I am now out of credits until late Thursday night.

Lawrence Kesteloot has released an updated copy of his trs80tools, now new version 2.8.6.

I don't know every change, but I know what he has been helping me with - trying to find a PC based TRS-80 disassembler that can come up with comparable output to a TRS-80 based one. In this regard his changes were:

1. Handle .SYS files that are raw dumps of floppy boot sectors. These work with the info, hexdump, and disasm commands.
2. Add --full and --data-comment flags to the disasm command.

The updated version can diassemble SYS files, including those without standard CMD file markers (like BOOT/SYS), and with the right command line options, can produce a listing file just like DISASSEM/CMD (with the address, hex, op code, and ascii in fixed columns).

You can download it for the Windows, Mac, and Linux at https://www.my-trs-80.com/tool/#installation.

And for those who want this kind of output there are a LOT of flags to override default behavior. I used
trs80-tool disasm --data-comment --upper --full --no-labels --listing --no-known --hex-format h

• Paid another US$80 to get some more Dutch and French TRS-80 manuals and books sent over. Will scan and post once they arrive from Belgium.
• Thanks to the versatility of CSS3, added a little floppy disk icon (💾) after download links throughout the site to further identify that they aree downloads.

Terry Stewart has written up a very nice article about his restoration of Dick Smith's Stock Control and Pricing program.

You can find it at https://www.classic-computers.org.nz/blog/2026-03-14-Adventures-in-Digital-Archaeology-Recovering-SCAP.htm

• The Model III NEWDOS/80 v2.0 Commented Disassembly is now complete. You can find the main page.

The next TRS-80 Trash Talk live show is Saturday, March 21, at 6:00PM Pacific Daylight Time / 9:00PM Eastern Daylight Time!

You can watch on the TRS-80 Trash Talk channel: https://www.youtube.com/channel/UCXkGugvdCkpkMDylVQb9gfg

If you want to participate in the live zoom session, reach out to trs80trashtalk at gmail dot com for information.

Gary K has kindly provided some additional scans. I have not looked to see how they differ, but more is always better!

Title:RS-232-C InterfacePublisher:TandyYear:1978Size:1,961,176OCRed:YesNotes:26-1145 / Black Cover / Set 2

Title:Tandy Technical Bulletin Notes and JumpersPublisher:TandyYear:1991Size:11,669,281OCRed:YesNotes:Set 2

Thank you, Gary!

Ian Mavric has provided some additional software! Thank you, Ian!

• Ball Turret Gunner
• Checker King
• Land Adventure
• Pirate's Cove Adventure
• TimeSet
• TString
• Veterans Ball Turret Gunner
• Z-Chess III

Ian Mavric has provided the missing manual for Air Flight Simulation! Thank you, Ian!

Sean O'Neill has let me know that David Shadoff has created a GIT to provide information about the JPC Products TC-8 Tape System for the TRS-80 Model I.

The GIT includes the EPROM, a KiCAD schematic, the manual, and the software.

The GIT can be found at https://github.com/dshadoff/TRS-80_TC-8.

I have redone the TRSDOS v2.3 DOS disassemblies now that so much other work had been done in the interim. I am also now using Lawrence Kesteloot's trs80-tool to handle my disassembly generation (previously I used David Goben's Model III Disassembler after using George/Peter Philip's TRLD to convert /SYS to /CMD).

Scott Toenniessen has provided some additional software! Thank you, Scott!

• 3-D Tic-Tac-Toe
• AOS Utilities Disk 1
• Disk Drive Analyzer
• Master Diskette Directory III v1.2
• SuperKeys
• XLR8er Installation Utility

Mark Casteleijn has written a utility for TRS-80 CP/M to make copying files between disk drives, RetroNET Internet Adapter, and the FreHD hard disk emulator

Examples of the command line are:

You can find the GIT at https://github.com/ontheslab/cppip/releases/tag/v1.10.

Sean O'Neill has provided a scan! Thank you, Sean!

Title:TRS-80 Technical Manual TroubleshootingPublisher:Radio ShackYear:1978Size:19,622,423Pages:24OCRed:YesNotes:Proof Copy / Set 3

The next (VERY EXPENSIVE TO SHIP) shipment from Cris Peters has arrived!

• Clefs Pour Le TRS-80 Modeles I et III Tome 1
• Clefs Pour Le TRS-80 Modeles I et III Tome 2
• Desktop Plan-80
• TRS-80 Model III-4 Handleiding Betreffende de Werking en de BASIC-Programmeertaal
• Handleiding Voor Level 1
• TRSDOS and DISK BASIC Handleiding
• Handleiding voor BASIC Level II
• DMP-110 Operations Manual

Thank you, Cris!

• Yesterday the Disk Request Form came under really heavy attack and I received hundreds and hundreds of fake forms. The interesting part was that the attackers had a slight misconfiguration, and they were bleeding code into the fields. So I provided Gemini with my html/cgi as well as all their code. Gemini was able to determine what software they were using and updated the cgi accordingly. At least it stopped until the next time.
• Claude usage caps are infuriating. I am trying to go through VTOS very carefully and the low caps are making this take a very very long time.

Although I keep hitting the CLAUDE.AI caps very quickly, I am trying to progress with the VTOS v4.0.2 disassembly. Their way-too-tight caps just make it slow going.

I want to give a special shout out to Tim Mann and to Lawyrence Kesteloot, both of whom have been extremely helpful in navigating SYS6/SYS. This system file is in an ISAM/PDS format,meaning that it is a bunch of overlapping routines all jammed into one file, and special code is used to point to a specific byte in the file and say 'start running here'. Traditional disassembly simply won't work.

Tim has been extremely helpful in explaining/helping with the ISAM/PDS structure and answering questions as they came up.

Lawrence updated his trs-80tool a few times to assist, most recently to allow for file extraction from disks and to understand the additional codes inside a PDS sys file to permit disassembly. Before he did this, I failed 4 times in trying to disassemble the file.

You can download Lawrence's updated trs-80tool at https://www.my-trs-80.com/tool/#installation. Changelog for the past few (related) updates is:

• v2.8.8 - Added --system flag to the convert command to extract system files from floppies. Updated so that disasm command understands LDOS-style PDS files for SYS6.SYS and SYS7.SYS, disassembling each overlay separately.
• v2.8.7 - Disassemble VTOS .SYS files better by handling the CMD block type 0x10 (yanked load block) like 0x01 (data).
• v2.8.6 - Handle .SYS files that are raw dumps of floppy boot sectors. These work with the info, hexdump, and disasm commands.

Thank you very much, Tim and Larence.

With extraordinary help from Tim Mann, the VTOS page is now up. It details the OS including the types of disks and copy protection, as well as a disassembly of the SYS files. It can be found on the VTOS page.

Tim Mann is still at it on his VTOS work. A lot of online documentation (and the source material it is based on) had talked about Tim Mann figuring out, back in the day, how to create a "Duplicator Disk", which just sat and polled floppy drives and made a "Master Disk" (the one which was sold to the public) whenever it found a diskette. None of those sources ever documented how. Tim has now re-figured that out, and kindly provided one based on the original image. A link to that has been added to the VTOS page. He also noted that the VTOS v3.0.1 image zip file, which contained 5 different VTOS v3.0.1 DMK's, had two which were badly hacked. Those two have been removed and the zip file updated. Thank you again, Tim, for not only your work here, but your work over the decades for the TRS-80!

John Gruver has provided some additional publications! Thank you, John!

Software

• Aerocomp Hard Disk Driver Boot Disk Creation Instructions
• AIDSPLUS-II with AutoKey v1.0
• ARC31 v2.00
• Auto-Mate v1.0
• Back-Rest Fast Hard Disk Backup
• Beep
• BSORT and MOD324
• ConvCPM v2.0
• Describe
• DiskMod EDTASM
• DISnDATa v1.0
• FileAid for AIDS Plus-II
• FM File Manager
• Formation Forms Management System
• Hard Disk Backup
• Home Accountant
• Le Script v1.2 Manual C
• Little Brother 86 Installation Manual for MSDOS
• Little Brother Database Manager Installation Manual for LDOS
• Little Brother Database Manager Installation Manual for Model 4
• Little Brother Database Manager Supplemental Documentation
• LS Comp
• LSI Help System
• LS QFB
• LU4 Library Utility v1.40
• LUM3 v1.23
• LUM4 v1.13
• LUMN3 v1.01
• Mach2
• MARC4 v2.01
• Montes Toolkit
• Montes Window
• Montezuma Micro 15MB Hard Disk Support
• Montezuma Micro CPM v2.2 Update to v2.3
• Montezuma Micro Public Domain Disks
• M-ZAL Compiler
• NEWDOS-80 v2.0 for Model I
• NSweep
• Nulu v1.1
• OverDrive
• Pro-ESP
• PRO-ZGraph
• Re-Vise
• SQ3 Squeeze v1.01
• SQ4 v1.01
• Sweep4 v1.00.00
• TBUG Z-80 Monitor and Debugging Aid
• Toolbelt for TRSDOS 6.x
• USQ3 v1.01
• USQ4 v1.01
• XARC4
• X-FTS File Transmission System
• XPort File Transport Utility v1.0
• XT-4 v1.6.8

Flyers

Title:8100 S-100 Bus AdapterPublisher:HUH ElectronicsYear:1978Size:1,314,739Pages:2OCRed:Yes

Title:VS-100 for the Model 4Publisher:Alpha ProductsYear:19xxSize:217,927Pages:1OCRed:Yes

Radio Shack Memos

Title:Radio Shack Memo - Printer Port Connections MemoPublisher:Radio ShackYear:1978Size:3,090,572Pages:4OCRed:Yes

Hardware Guides

Title:Parts Required to Add Disk Drives to TRS-80Publisher:PercomYear:19xxSize:3,272,059Pages:3OCRed:Yes

Title:RAM Upgrade InstructionsPublisher:Author UnknownYear:1985Size:2,973,772Pages:2OCRed:Yes

Title:TRS-80 Serial I-O Preliminary DocumentationPublisher:Electronic SystemsYear:1978Size:5,302,841Pages:5OCRed:Yes

Title:Your Hard Disk Drive and YouPublisher:Montezuma MicroYear:19xxSize:3,148,860Pages:2OCRed:Yes

Tim Mann has gone through all known copies of VTOS on DMK and has prepared a complete set of Duplicator/Master/System/Data disks for what he could determine is the purest/best copy archived:

• VTOS v3.0.0 Set - Duplicator/Master/System/Data - Created by Tim Mann
• VTOS v3.0.1 Set - Duplicator/Master/System/Data - Created by Tim Mann

Nickmann Studios has developed a new game for the TRS-80 - "House on the Edge of the Crater"

The authorities of the age of normality have exiled the most creative people to the moon: artists, scientists, dangerous eccentrics, and keepers of great secrets.
You are Yordi, the reporter.
Conduct interviews with the residents, explore the house on the edge of the crater and bring back to earth the knowledge that could transform the cold world of the age of normality.
Requirements for a successful mission: Conduct 9 interviews and obtain all 3 keys.

It is a 'name your price' download - You can find all the information and download links at https://nickmann-studio.itch.io/crater

The first, which I am 2/3 of the way through, is updating the TRSDOS v1.3 disassembly pages to merge in the official Frank Durda source code labels and comments. This is tough going because of misformed pages to begin with. It also uses a ton of credits because I have to feed in a disassembly, the HTML (which is about 500MB each), and all of Frank's source and dependencies.

The second, is to re-OCR the documents. There are currently 7,963 zips in the 'publications' folder. The process uses cURL to upload the PDF to the Mistral API and retrieve a unique file ID, which is then passed to a PowerShell script to trigger the OCR model and generate a text sidecar, which is then used by OCRmyPDF to inject a searchable text layer back into the original document. During this final assembly, Tesseract performs a local OCR pass to handle any missed coordinates and refine text placement, while Ghostscript acts as the rendering engine to optimize the PDF's internal structure and compress the file for archival storage. Mistral is utilized because it employs the new Vision-Language Model (VLM) that is better than the basic pattern-matching of legacy tools by using deep contextual understanding to accurately "read" and reconstruct text even through the heavy noise, dot-matrix distortion, and ink-bleed common older publications. It is possible that the JSON can be used for indexing the archive's full-text search engine or programmatically extracting metadata from the magazines.

• Thanks to a program writing by Gemini, I have gotten JSON OCR from Mistral for all 7,963 zips in the 'publications' folder, although a few PDF's had to be regenerated. I have looked at the output, and it is by no means perfect, but it is orders of magnitude better than what was there from either AABBYY Finereader or Adobe Acrobat Pro.
  UPDATE: At this point, I have re-uploaded all downloadable PDF's and every one of them should have the .json and sidecar.txt in it. I am, however, starting the "Phase 2" of creating PDF's with the Mistral OCR replacing the existing OCR, and the files will be re-uploaded once that occurs.
• A site visitor Airton was kind enough to point out that there are discrepancies between the Level 1 source in github, his work on the Level 1 source, and the Level 1 disassembled page here.
  UPDATE:The page has now been corrected.
• Downloads for Level 1 programs have been fixed, thanks to Quentin pointing out that they were not functioning.
• The TRSDOS v1.3 disassembly re-do project is winding down. All 15 SYS files have been reprocessed against Frank Durda's source file. I plan on doing BASIC/CMD as well to finish up the set once the credits refresh. I also realized that XFERSYS was never disassembled, so that will be on the to-do list as well. I wish all the background information and files required to do these didn't use up so many credits.
